Certification | CE
FCC
C-Ticket
VCCI
BSMI
CCC |
LED indicators | Yes |
Product colour | Silver |
Form factor | 1U |
Rack mounting | Yes |
Safety | cUL, CB, CE, CCC, BSMI |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (max) | 68.67 W |
Security algorithms | SSH |
DHCP features | DHCP server |
IGMP snooping | Yes |
Access Control List (ACL) | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -5 - 50 °C |
Operating relative humidity (H-H) | 0 - 95% |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Switch type | Managed |
Switch layer | L2/L3 |
MIB support | Bridge, MIB-II |
Weight | 3.1 kg |
Width | 440 mm |
Height | 44 mm |
Depth | 210 mm |
Networking standards | IEEE 802.1Q |
Copper ethernet cabling technology | 10GBASE-T |
Port mirroring | Yes |
Auto MDI/MDI-X | Yes |
10G support | Yes |
VLAN support | Yes |
Number of VLANs | 4000 |
Spanning tree protocol | Yes |
Head-of-line (HOL) blocking | Yes |
Broadcast storm control | Yes |
Flow control support | Yes |
Link aggregation | Yes |
Package depth | 546 mm |
PACKAGE WEIGHT | 4.38 kg |
Package width | 349 mm |
Package height | 96 mm |
Management protocols | SNMPv1/2/3, Telnet, SSH, TFTP, RMON v1/v21 |
Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
SFP+ module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Harmonized System (HS) code | 85176990 |
MAC Address Table | 16000 entries |
Jumbo Frames support | Yes |
Switching capacity | 200 Gbit/s |
Number of queues | 8 |
Store-and-forward | Yes |
Power Over Ethernet (PoE) | No |
Multicast support | Yes |
