Product colour | Black |
Stackable | Yes |
LED indicators | Yes |
Rack mounting | Yes |
Number of fans | 0 fan(s) |
Power consumption (typical) | 30 W |
Power source | AC |
Power supply included | Yes |
MAC address filtering | Yes |
BPDU filtering/protection | Yes |
Loop protection | Yes |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
SSH/SSL support | Yes |
PASSWORD PROTECTION | Yes |
Authentication type | IEEE 802.1x |
IP-MAC-Port binding | Yes |
DHCP features | DHCP relay |
Access Control List (ACL) rules | 1500 |
Web-based management | Yes |
Configuring Location Settings (CLI) | Yes |
Switch type | Managed |
Quality of Service (QoS) support | Yes |
Switch layer | L2+ |
Width | 175 mm |
Depth | 30 mm |
Weight | 1.8 kg |
Height | 44 mm |
Networking standards | IEEE 802.3x |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
10G support | No |
VLAN support | Yes |
Rate limiting | Yes |
Port mirroring | Yes |
Active link detection | Yes |
Spanning tree protocol | Yes |
Number of VLANs | 4000 |
Auto-sensing | Yes |
IP routing | Yes |
Auto-negotiation | Yes |
Rack mount kit | Yes |
CABLES INCLUDED | AC |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Installed SFP modules quantity | 2 |
Number of static routes | 8000 |
Static route | Yes |
Forwarding rate | 14.88 Mpps |
Switching capacity | 20 Gbit/s |
Store-and-forward | Yes |
Throughput | 10 Gbit/s |
Power Over Ethernet (PoE) | No |
Multicast features | Multicast forwarding |
Multicast support | Yes |
