connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 48 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of installed SFP modules | 4 |
console port | RJ-45 |
network | |
Eigenschaft | Power over Ethernet (PoE) |
safety | |
DHCP functions | DHCPv6 snooping |
Design | |
form factor | 1U |
Product color | Grau |
housing material | Metall |
International degree of protection (IP code) | IP20 |
Services | |
storage capacity | 1 MB |
Flash memory | 2000 MB |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (standard operation) | 48,64 W |
Power consumption (max.) | 462,8 W |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 380 W |
operating conditions | |
operating temperatur | -5 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 5 - 95% |
operating height | 0 - 5000 m |
storage height | 0 - 5000 m |
heat dissipation | 165,96 BTU/h |
weight and dimensions | |
broad | 442 mm |
depth | 220 mm |
height | 43,6 mm |
