Certification | CE, RoHS, REACH |
Product colour | Black |
LED indicators | Yes |
DC input voltage | 52 V |
Input current | 2.3 A |
AC input voltage | 230 V |
Operating temperature (T-T) | -10 - 40 °C |
Storage relative humidity (H-H) | -20 - 60% |
Operating relative humidity (H-H) | 5 - 90% |
Weight | 1.2 kg |
Depth | 105 mm |
Height | 28 mm |
Width | 190 mm |
Networking standards | IEEE 802.3af |
VLAN support | Yes |
MAC address auto-aging supported | Yes |
MAC address auto-learning supported | Yes |
PACKAGE WEIGHT | 1.4 kg |
Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports quantity | 10 |
MAC Address Table | 1000 entries |
Store-and-forward | Yes |
Total Power over Ethernet (PoE) budget | 96 W |
Power over Ethernet (PoE) power per port | 30 W |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 8 |
Power over Ethernet (PoE) type supported | PoE+ |
