management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Rackmontageset |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 8 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 8 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Number of VLANs | 32 |
data transmission | |
Routing/Switching Capacity | 16 Gbit/s |
Transferrate | 11,904 Mpps |
MAC-Adressentabelle | 4000 Eintragungen |
Jumbo-Frames | 9000 |
Data packet buffer memory | 1,5 MB |
safety | |
Design | |
Product color | Schwarz |
LED indicators | Aktivität, Link, Leistung |
Services | |
Flash memory | 2 MB |
noise level | 0 dB |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (standard operation) | 6 W |
operating conditions | |
operating temperatur | 0 - 45 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
heat dissipation | 20,4 BTU/h |
weight and dimensions | |
broad | 215 mm |
depth | 150 mm |
height | 44,5 mm |
Weight | 720 g |
scope of delivery | |
Supplied cables | AC |
packaging type | Box |
package weight | 1,19 kg |
certificates | |
certification | CE, UKCA, FCC Part 15, Subpart B Class B, RoHS |
logistic data | |
Country of origin | China |
