Certification | FCC, CE, RoHS |
Product colour | Black |
LED indicators | Yes |
Power supply included | Yes |
Input current | 0.6 A |
Input voltage | 5 V |
Power consumption (max) | 2.82 W |
Power source | DC |
IGMP snooping | Yes |
Heat dissipation | 9.62 BTU/h |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Web-based management | Yes |
Quality of Service (QoS) support | Yes |
Switch layer | L2 |
Switch type | Unmanaged |
Depth | 98 mm |
Height | 26 mm |
Width | 99.8 mm |
Port mirroring | Yes |
Auto-negotiation | Yes |
Auto MDI/MDI-X | Yes |
Virtual LAN features | Port-based VLAN |
Networking standards | IEEE 802.1Q |
Link aggregation | Yes |
Number of VLANs | 32 |
10G support | No |
VLAN support | Yes |
Copper ethernet cabling technology | 1000BASE-T |
Package depth | 125 mm |
Quick start guide | Yes |
User guide | Yes |
Package width | 128 mm |
Package Type | Box |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Package height | 92 mm |
Gigabit Ethernet (copper) ports quantity | 5 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 5 |
MAC Address Table | 2000 entries |
Packet buffer memory | 1 MB |
Forwarding rate | 7.44 Mpps |
Store-and-forward | Yes |
Jumbo Frames support | Yes |
Jumbo frames | 16000 |
Switching capacity | 10 Gbit/s |
Power Over Ethernet (PoE) | No |
