Certification | CE, FCC, RoHS |
Product colour | Black |
Form factor | 1U |
Number of fans | 3 fan(s) |
Rack mounting | Yes |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power source | AC |
Power supply included | Yes |
MAC address filtering | Yes |
Authentication | Auto VLAN, Guest VLAN |
Static port security | Yes |
SSH/SSL support | Yes |
DHCP features | DHCP server |
BPDU filtering/protection | Yes |
Access Control List (ACL) | Yes |
IGMP snooping | Yes |
IP-MAC-Port binding | Yes |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Heat dissipation | 2169.2 BTU/h |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
Configuring Location Settings (CLI) | Yes |
System event log | Yes |
Cloud-managed | Yes |
Switch layer | L2+ |
ARP inspection | Yes |
Switch type | Managed |
Depth | 330 mm |
Height | 44 mm |
Width | 440 mm |
Networking standards | IEEE 802.1D |
Broadcast storm control | Yes |
VLAN support | Yes |
Link aggregation | Yes |
Flow control support | Yes |
10G support | Yes |
Port mirroring | Yes |
Spanning tree protocol | Yes |
Rate limiting | Yes |
Head-of-line (HOL) blocking | Yes |
INTERNAL MEMORY | 512 MB |
Flash Memory | 32 MB |
Quick start guide | Yes |
Rack rails | Yes |
CABLES INCLUDED | AC |
Basic switching RJ-45 Ethernet ports quantity | 48 |
console port | RJ-45/Micro-USB |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
SFP+ module slots quantity | 4 |
Harmonized System (HS) code | 85176990 |
Jumbo Frames support | Yes |
MAC Address Table | 16000 entries |
Switching capacity | 176 Gbit/s |
Forwarding rate | 130.9 Mpps |
Jumbo frames | 9216 |
Store-and-forward | Yes |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 48 |
Total Power over Ethernet (PoE) budget | 500 W |
Power over Ethernet (PoE) power per port | 30 W |
Multicast support | Yes |
