Design | |
Product color | Weiß |
housing material | Polycarbonat (PC) |
LED indicators | Status |
features | |
antenna type | Intern |
Antenna gain level (max) | 6 dBi |
number of antennas | 4 |
Services | |
Eigenschaft | AC-Netzadapter |
Display-Typ | LCM |
processor manufacturer | ARM |
processor family | ARM Cortex |
processor | Cortex-A53 |
processor clock speed | 1500 MHz |
Number of processors installed | 1 |
storage capacity | 3000 MB |
logs | |
Router protocol | OSPF |
network | |
Ethernet LAN data transfer rates | 10,100,1000,2500,10000 Mbit/s |
mesh standard | IEEE 802.1Q |
Data transfer speed WiFi | 1,2,5.5,6,6.5,9,11,12,18,24,36,48,54,300 Mbit/s |
frequency band | 2.4, 5, 6 GHz |
data transfer rate | 5,7 Gbit/s |
safety | |
Supported security algorithms | 802.1x RADIUS, IPSec, PPSK, TLS, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
WAN port | Ethernet (RJ-45) |
management functions | |
energy | |
Power consumption (max.) | 22 W |
input voltage | 100 - 240 V |
input current | 5 A |
Elektromagnetischer Schutz (EMP) (Luft) | 8 kV |
Elektromagnetischer Schutz (EMP) (Kontakt) | 4 kV |
weight and dimensions | |
broad | 117 mm |
depth | 117 mm |
height | 42,5 mm |
Weight | 422 g |
scope of delivery | |
Supplied cables | LAN (RJ-45), Leistung |
operating conditions | |
operating temperatur | -10 - 40 °C |
Operating relative humidity | 5 - 95% |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), Industry Canada (IC) |
screen | |
screen size | 2,44 cm (0.96") |
