Design | |
device type | Router für Mobilfunknetz |
Product color | Schwarz |
housing material | Aluminium |
Eigenschaft | Benutzerhandbuch |
Ethernet LAN characteristics | |
Interface type Ethernet LAN | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3u |
Wireless LAN functions | |
WLAN-Standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
mobile network | |
data network | 3G, 4G, LTE |
4G-Standards | LTE |
Number of SIM cards | 2 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
safety | |
Supported security algorithms | AES-CCMP, SNMPv2, SNMPv3, SSID, TKIP, WPA-PSK, WPA2-EAP, WPA2-PSK, WPA3-EAP, WPA3-SAE |
Services | |
processor manufacturer | Mediatek |
processor clock speed | 0,58 GHz |
RAM capacity | 0,128 GB |
RAM type | DDR2 |
Installed operating system | RutOS |
Antenna | |
antenna type | Extern |
Antenna connector type | SMA/RP-SMA |
number of antennas | 4 |
energy | |
energy source | Gleichstrom |
operating conditions | |
operating temperatur | -40 - 50 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 110 mm |
depth | 100 mm |
height | 50 mm |
Weight | 297 g |
