WAN connection | |
Eigenschaft | Betriebsanleitung |
WAN connection type | SFP |
Wireless LAN functions | |
WiFi band | Dual-Band (2,4 GHz/5 GHz) |
WLAN data transfer rate (max.) | 3000 Mbit/s |
WLAN data transfer rate (first band) | 574 Mbit/s |
WLAN data transfer rate (second band) | 2402 Mbit/s |
network | |
Interface type Ethernet LAN | Gigabit Ethernet |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
Number of VPN tunnels | 50 |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
management functions | |
safety | |
Supported security algorithms | WPA, WPA2, WPA3-Enterprise |
logs | |
Router protocol | OSPF, RIP |
Design | |
Product color | Schwarz |
LED indicators | System, USB, WAN, WLAN |
product type | Desktop-/Pol-Router |
scope of delivery | |
Antenna | |
The Antenna Design | Extern |
Antenna gain level (max) | 4,5 dBi |
number of antennas | 3 |
features | |
storage capacity | 512 MB |
Internal storage type | DDR4 |
Flash memory | 128 MB |
certification | CE, FCC, RoHS |
energy | |
energy source | Gleichstrom |
output voltage | 12 V |
output current | 2 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 226 mm |
depth | 131 mm |
height | 35 mm |
