WAN connection | |
Eigenschaft | Entfernbare Antennen |
WAN connection type | RJ-45 |
Wireless LAN functions | |
WiFi band | Einzelband (2,4GHz) |
Top WLAN-Standard | Wi-Fi 4 (802.11n) |
WLAN data transfer rate (max.) | 300 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
WLAN data transfer rate (first band) | 300 Mbit/s |
network | |
Interface type Ethernet LAN | Schnelles Ethernet |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
wiring technology | 10/100Base-T(X) |
mesh standard | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Number of guest networks (2.4 GHz) | 1 |
VPN-Server | PPTP VPN, OpenVPN |
Number of VPN tunnels | 10 |
mobile network | |
Cellular Network Generation | 4G |
3G standards | DC-HSPA+, HSPA, HSPA+, UMTS |
4G-Standards | LTE-TDD & LTE-FDD |
Supported UMTS bandwidths | 900,2100 MHz |
supported 4G bandwidths | 800,900,1800,2100,2300,2500,2600 MHz |
SIM card type | MicroSIM |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 2 |
RJ-11 ports quantity | 1 |
management functions | |
safety | |
Supported security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
Firewall | : DoS, SPI Firewall, IP and MAC Address Binding |
logs | |
VoIP Protocol | SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.729AB, G.726 |
Design | |
Product color | Schwarz |
product type | Tabletop-Router |
scope of delivery | |
Supplied cables | LAN (RJ-45) |
Antenna | |
The Antenna Design | Extern |
number of antennas | 2 |
energy | |
energy source | Gleichstrom |
output voltage | 12 V |
output current | 1 A |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
humidity during storage | 5 - 90% |
weight and dimensions | |
broad | 202 mm |
depth | 141 mm |
height | 33,6 mm |
package weight | 640 g |
logistic data | |
Goods tariff number (HS) | 85176990 |
