Receiver sensitivity | 300M: -71dBm@10% PER150M: -75dBm@10% PER54M: -78dBm@10% PER11M: -93dBm@8% PER6M: -92dBm@10% PER1M: -96dBm@8% PER |
5 GHz | No |
Ethernet LAN data rates | 10 |
2.4 GHz | Yes |
Frequency Band | 2.4 - 2.4835 GHz |
Networking standards | IEEE 802.11g |
Quality of Service (QoS) support | Yes |
Wi-Fi Multimedia (WMM)/(WME) | Yes |
Rate limiting | Yes |
Maximum data transfer rate | 300 Mbit/s |
6 GHz | No |
Automatic channel selection | Yes |
Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
Wireless isolation | Yes |
Certification | CE, FCC, RoHS |
Reset button | Yes |
LED indicators | Yes |
Product colour | White |
Placement | Ceiling, Wall |
On/off switch | Yes |
Power Over Ethernet (PoE) | Yes |
Power consumption (typical) | 2.8 W |
Output voltage | 9 V |
Output current | 0.6 A |
MAC address filtering | Yes |
Security algorithms | HTTPS |
System status alarm | Y |
Number of SSID supported | 8 |
Access Control List (ACL) | Yes |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 5 - 90% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -40 - 70 °C |
Web-based management | Yes |
Syslog | Yes |
Depth | 172.3 mm |
Width | 189.4 mm |
Height | 29.5 mm |
Package width | 268 mm |
Package height | 69 mm |
Package depth | 246 mm |
PACKAGE WEIGHT | 600 g |
Mounting Kit | Yes |
AC adapter included | Yes |
Number of products included | 1 pc(s) |
WAN connection | Wi-Fi |
Ethernet LAN (RJ-45) ports | 1 |
Antenna gain level (max) | 4 dBi |
Antenna type | Internal |
Antennas quantity | 2 |
Harmonized System (HS) code | 85176990 |
