features | |
Eigenschaft | Nachhaltigkeitskonformität |
Maximum data transfer rate | 300 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
Ethernet LAN data transfer rates | 10,100 Mbit/s |
frequency band | 2.4 GHz |
mesh standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Virtual LAN functions | Tagged VLAN, VLAN mapping |
Transmission power (CE) | 20 dbm |
Transmission power (FCC) | 22 dbm |
safety | |
Supported security algorithms | WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
Features Service Set Identifier (SSID) | Multiple SSIDs |
Anzahl der SSID-Unterstützung | 8 |
logs | |
management logs | HTTP/HTTPS, SNMP, Telnet |
management functions | |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
energy | |
Power over Ethernet (PoE) type supported | Passive PoE |
output voltage | 24 V |
output current | 0,6 A |
Power consumption (max.) | 3,12 W |
Design | |
placement | Stange, Wand |
Product color | Weiß |
International degree of protection (IP code) | IP65 |
LED indicators | Leistung |
certification | CE, FCC, RoHS |
Antenna | |
antenna type | Extern |
Antennenrichtungsart | Mit kugelförmiger Richtcharakteristik |
antenna functions | Abnehmbare Antenne |
number of antennas | 2 |
Antenna gain level (max) | 3 dBi |
Services | |
Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
weight and dimensions | |
broad | 216 mm |
depth | 46 mm |
height | 27 mm |
package weight | 620 g |
packaging type | Box |
scope of delivery | |
Number of products included | 1 Stück(e) |
Supplied cables | AC |
operating conditions | |
Operating relative humidity | 10 - 90% |
operating temperatur | -30 - 65 °C |
Storage temperature range | -40 - 70 °C |
humidity during storage | 5 - 90% |
sustainability | |
