| features | |
| USV-Topology | Doppelwandler (Online) |
| output capacity | 5 kVA |
| output power | 4500 W |
| waveform | Sine |
| Input operating voltage (min) | 100 V |
| Input operating voltage (max) | 275 V |
| input frequency | 40 - 70 Hz |
| Output operating voltage (min) | 220 V |
| Output operating voltage (max) | 240 V |
| Regulation of the output frequency | 50/60 Hz |
| Anstieg der Energiemenge | 480 J |
| efficiency | 94,1% |
| Crest-Factor | 3:1 |
| Eigenschaft | Software-CD |
| noise level | 55 dB |
| connections and interfaces | |
| AC plug types | C13-Koppler, C19-Koppler |
| plug | Hardwire |
| Number of AC outlets | 12 AC-Ausgänge |
| Number of output IEC jumpers | 2 |
| Serial interface | RJ-45 |
| battery | |
| Rechargeable battery technology | Plombierte Bleisäure (VRLA) |
| battery capacity | 845 VAh |
| Typical backup time at full load | 4 min |
| Typical backup time at half load | 11,8 min |
| Battery life (max.) | 5 Jahr(e) |
| battery charge time | 1,5 h |
| Design | |
| Product color | Schwarz |
| Display-Typ | LCD |
| LED indicators | Status |
| International degree of protection (IP code) | IP20 |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -15 - 45 °C |
| Operating relative humidity | 0 - 95% |
| humidity during storage | 0 - 95% |
| operating height | 0 - 3000 m |
| storage height | 0 - 15000 m |
| certificates | |
| Konformitätsbescheinigungen | RoHS |
| certification | REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
| scope of delivery | |
| Supplied cables | USB-Kabel |
| sustainability | |
| sustainability certificates | ENERGY STAR |
| weight and dimensions | |
| broad | 130 mm |
| depth | 719 mm |
| height | 432 mm |
| Weight | 54,4 kg |
| package weight | 63,6 kg |
| logistic data | |
| products per pallet | 6 Stück(e) |
| Goods tariff number (HS) | 85078000 |
| Gesamter Kohlendioxid-Fußabdruck (kg of CO2e) | 8386,06 |
