| Processor manufacturer | Intel |
| Compatible processor series | Intel® Pentium® |
| Processor Socket | LGA 1200 (Socket H5) |
| On-board graphics card memory | 64 MB |
| Graphics card family | ASPEED |
| Graphics card | AST2600 |
| Motherboard form factor | micro ATX |
| MOTHERBOARD CHIPSET | Intel C252 |
| Motherboard chipset family | Intel |
| Component for | Server |
| Supported memory module capacities | 4GB |
| Memory channels | Dual-channel |
| Supported memory clock speeds | 3200 MHz |
| Maximum internal memory | 128 GB |
| Memory slots type | DIMM |
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 4 |
| Operating temperature (T-T) | 10 - 50 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Depth | 244 mm |
| Width | 244 mm |
| LAN controller | Intel® I210-AT |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| EPS power connector (8-pin) | Yes |
| Serial port headers | 1 |
| Number of SATA III connectors | 6 |
| ATX Power connector (24-pin) | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 2 |
| PACKAGE WEIGHT | 1.3 kg |
| Supported storage drive interfaces | M.2, SATA III |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| Harmonized System (HS) code | 84733020 |
