Processor Socket | Socket sTR5 |
Processor manufacturer | AMD |
Compatible processor series | AMD Ryzen Threadripper 1000 Series |
Parallel processing technology support | Not supported |
Component for | Workstation |
Motherboard form factor | ATX |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD TRX50 |
Audio output channels | 5.1 channels |
audio chip | Realtek ALC888S |
ECC сompatibility | ECC |
Supported memory clock speed (max) | 5200 MHz |
Supported memory clock speeds | 5200 MHz |
Supported memory module capacities | 1024GB |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR5-SDRAM |
Maximum internal memory | 4 TB |
Memory voltage | 1.1 |
Operating relative humidity (H-H) | 10 - 85% |
Storage temperature (T-T) | 0 - 50 °C |
Operating temperature (T-T) | -20 - 60 °C |
Storage relative humidity (H-H) | 10 - 95% |
Depth | 243.8 mm |
Width | 304.8 mm |
Wi-Fi | No |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
LAN controller | Broadcom BCM5720 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
TPM connector | Yes |
CPU fan connector | Yes |
USB 2.0 connectors | 2 |
Number of SATA III connectors | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
Number of chassis fan connectors | 7 |
BIOS Type | AMI |
System management BIOS (SMBIOS) version | 3.6 |
BIOS memory size | 32 Mbit |
ACPI version | 6.5 |
Supported storage drive types | HDD & SSD |
RAID levels | 10 |
Number of HDDs supported | 4 |
Supported storage drive interfaces | M.2, SATA III |
Raid Support | Yes |
USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
VGA (D-Sub) ports quantity | 1 |
COM ports quantity | 1 |
IPMI LAN (RJ-45) port | Yes |
Ethernet LAN (RJ-45) ports | 2 |
PCI Express x16 (Gen 5.x) slots | 2 |
