Specific features | 6-stage charging algorithm |
Polarity reverse circuit protection | Yes |
Night mode | Yes |
Bluetooth | Yes |
Voltage monitoring | Yes |
Product Type | Loader |
Brand compatibility | Victron Energy |
Programmable | Yes |
Overheat protection | Yes |
Short circuit protection | Yes |
Number of batteries supported simultaneously | 3 |
Can be used as power supply | Yes |
Remote on/off switch | Yes |
Dedicated application | VictronConnect |
Power plug | Yes |
LED indicators | Yes |
International Protection (IP) code | IP22 |
Product colour | Blue |
Material | Aluminium |
Built-in Display | No |
Battery-connection | Screw terminals 16 mm² / AWG6 |
Integrated charging cable | Yes |
Efficiency | 93% |
Power consumption (idle) | 0.5 W |
Charging current | 20 A |
Frequency | 45 / 65 Hz |
Input voltage range | 180 - 265 V |
DC battery voltage | 12 V |
Charging voltage (absorption) | 14.4 V |
Charging voltage (liquid) | 13.8 V |
Storage relative humidity (H-H) | 0 - 98% |
Operating temperature (T-T) | -40 - 60 °C |
Depth | 65 mm |
Height | 235 mm |
Weight | 1.3 kg |
Width | 108 mm |
Lead cable length | 1,5 m |
