Certification | EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1, EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 / ECE R10-5 |
Power protection features | Under voltage |
International Protection (IP) code | IP21 |
Power supply type | Indoor/outdoor |
Efficiency | 93% |
Power current type | DC/AC |
Purpose | Solar panel |
Connectivity | Ethernet |
DIP Switch | Yes |
Three-phase and parallel operation | Yes |
Cross-section connections supported | 35 mm² |
Product colour | Blue |
Material | ABS |
Built-in Display | No |
Number of VE.Bus ports | 1 |
AC input voltage | 187 - 265 V |
Input voltage | 9.5 - 17 V |
Output voltage | 230 V |
Apparent power | 1200 VA |
Frequency | 50 Hz |
DC input voltage | 12 V |
Peak power | 2400 W |
Frequency range | 45 - 65 Hz |
Charging the current battery | 50 A |
Charging voltage (liquid) | 13.8 V |
Ongoing charging of the starter battery | 1 A |
Power at zero load | 10 W |
Charging voltage (absorption) | 14.4 V |
Output power at 65°C | 600 W |
Output power at 25°C | 1000 W |
Output power at 40°C | 900 W |
Operating relative humidity (H-H) | 0 - 95% |
Operating temperature (T-T) | -40 - 65 °C |
Depth | 100 mm |
Weight | 8.2 g |
Height | 406 mm |
Width | 250 mm |
Quantity per pack | 1 pc(s) |
Set contents | VE.Bus Smart Dongle |
