The Lenovo ThinkCentre M90q G5 is a powerful business computer packed into a compact Tiny chassis. Despite its small size, the device features a free PCIe 4.0 x8 slot for exciting expansion cards. It can dock directly with the Lenovo Tiny-in-One (TIO) monitor without the need for tools, creating a convenient all-in-one PC solution. A special feature of this model includes two RJ-45 Ethernet network ports and two installed 512GB SSD drives.
Key Features:
- Operating System: Windows 11 Pro 64-bit
- Processor: Intel Core i7-14700 (20C/28T/33MB)
- Processor specifications: 8xP-core 2.1/5.3GHz, 12xE-core 1.5/4.2GHz
- Chipset: Intel Q670
- Graphics: Integrated Intel UHD Graphics 770
- Intel® vPro® Enterprise
- Memory: 32GB DDR5 5600MHz SODIMM (2x16)
- Maximum Memory: 64GB 5600MHz (2x32GB)
- Drive #1: 512GB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal 2.0
- Drive #2: 512GB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal 2.0
- Internal 2W Premium speaker
- LAN #1 Intel Gigabit Ethernet 100/1000
- LAN #2 Realtek 2.5 Gigabit Ethernet RTL8125BGS
- WLAN Intel Wi-Fi 6E AX211 802.11ax 2x2 + BT 5.3
- Included: Lenovo USB keyboard and optical USB mouse
- Front Panel: 1xUSB-C Gen2, 2xUSB-A Gen2, 3.5mm headphone/microphone combo
- Back Panel: 2xDisplayPort, HDMI 2.1 TMDS, 2xUSB-A Gen1, 2XUSB-A Gen2, RJ-45
- One free PCIe 4.0 x8 low profile expansion slot
- Integrated TPM 2.0 security chip, TCG/FIPS 140-2 certified
- Kensington security lock slot (3x7mm)
- Included: VESA Mount bracket
- External power supply: 230W 89%
- Military-grade durability: MIL-STD-810H
- Basic warranty: 3 years Premier NBD on-site
- Weight: 1.25kg
Lenovo CO2 Offset Gen2 emission compensation
- The carbon dioxide emissions generated during the manufacturing, transportation, and electricity consumption of this device throughout its lifecycle have been compensated through the global Climeco organization, supporting UN-approved environmental projects.
Environmental and energy certifications
- ENERGY STAR® 8.0, EPEAT™ Gold Registered, ErP Lot 3, RoHS compliant, TCO Certified 9.0
Product life cycle used in emission assessments, years | 4 |
Product life cycle CO2 emissions, kg (manufacturer?s estimate) | 302 |
RAID уровни | 0/1 |
RAID контроллер | Yes |
Green certifications | Energy Star 8.0 |
Мощность динамика, Вт | 2 |
Операционная система (в комплекте) | Windows 11 Pro |
Разъёмы | USB-C (Gen2) |
Семейство (серия) процессора | Intel Core i7 |
Число ядер процессора | 20 |
Тип твердотельного накопителя | M.2 PCIe NVMe |
Общая вместимость хранилища | 1 TB SSD |
Внутренняя память | 32 GB |
Максимальный объём внутренней памяти, GB | 64 GB |
Графический адаптер | Intel UHD Graphics 770 |
Тактовая частота процессора, GHz | 1.30 |
Чипсет материнской платы | Intel Q670 |
Слоты под память (свободных) | |
Модель процессора | Intel Core i7-14700T (Max. 5.20GHz, 33M, 20C) |
Адаптер питания, Ватт | 230 |
Изготовитель процессора | Intel |
Размеры Ш x Г x В, мм | 179 x 182.9 x 36.5 |
Тип внутренней памяти | DDR5 |
Вес, g | 1250 |
Частота памяти, MHz | 5600 |
Технология Intel Virtualization | VT-x / VT-d / VT-rp |
Версия Bluetooth | 5.3 |
Тип графического адаптера | Intel UHD Graphics |
Тип WLAN-а | Intel Wi-Fi 6E AX211, 802.11ax 2x2 |
USB-A (USB 3.2) ports quantity | 6 |
Intel Smart Cache, МБ | 33 |
Intel Turbo Boost, ГГц | 5.20 |
Количество портов HDMI | 1 |
Слоты под память | 2 |
Количество портов DisplayPorts | 3 |
WLAN антенны | 2x2 |
Количество производительных ядер | 8 |
USB-C (USB 3.2) ports quantity | 1 |
Версия криптопроцессорного модуля (TPM) | 2.0 |
Количество эффективных ядер | 12 |
Количество портов Ethernet LAN (RJ-45) | 2 |
Количество установленных дисков | 2 |
Вай-фай | Yes |
Встроенные динамики | Yes |
Intel HyperThreading технология | Yes |
Выделенная видеопамять (ГБ) | Uses system memory |
Интел vPro | Yes |
Слот для тросового замка | Yes |
Беспроводная локальная сеть (WLAN) | Yes |
Оптический привод | No |
Считыватель карт памяти | No |
Bluetooth | Yes |
