screen | |
Eigenschaft | Wandmontage |
screen size | 38,1 cm (15") |
screen technology | LCD |
Display resolution | 1024 x 768 Pixel |
brightness | 240 cd/m² |
Touchscreen Technology | Projizierts Kapazitivsystem |
reaction time | 16 ms |
contrast ratio | 800:1 |
angle of view, horizontal | 160° |
angle of view, vertical | 150° |
Number of colors of the display | 16,2 Millionen Farben |
Horizontal scan area | 30 - 60 kHz |
Vertical scan area | 50 - 75 Hz |
Wiederholfrequenz | 60 Hz |
connections and interfaces | |
Number of HDMI ports | 1 |
Number of DisplayPort connections | 1 |
Design | |
Product color | Schwarz |
screen shape | Flach |
Panel mounting interface | 75 x 75,100 x 100 mm |
Services | |
menu languages | Vereinfachtes Chinesisch, Traditionelles Chinesisch, Deutsch, Englisch, Spanisch, Französisch, Italienisch, Japanisch |
Mean Time Between Failures (MTBF) | 50000 h |
energy | |
Power consumption (standard operation) | 12,5 W |
power consumption (off) | 0,5 W |
package weight | 4,7 kg |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 20 - 80% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 10 - 95% |
logistic data | |
Goods tariff number (HS) | 85285210 |
features | |
Technical details | |
Konformitätsbescheinigungen | RoHS |
Other functions | |
aspect ratio | 4:3 |
Backlight type | LED |
Digital horizontal frequency | 30 - 60 kHz |
Digital vertical frequency | 50 - 75 Hz |
Display, visible area WxH | 304,1 x 228,1 mm |
Height (without stand) | 284,9 mm |
Gewicht (ohne Standfuß) | 2,9 kg |
Depth (without stand) | 35,6 mm |
power supply type | Gleichstrom |
