| screen | |
| screen size | 60,5 cm (23.8") |
| Display resolution | 1920 x 1080 Pixel |
| HD-Typ | Full HD |
| Native Aspect Ratio | 16:9 |
| screen technology | LCD |
| Panel-Typ | IPS |
| Backlight type | W-LED |
| brightness (typical) | 250 cd/m² |
| reaction time | 8 ms |
| Eigenschaft | Neigungsverstellung |
| screen shape | Flach |
| Supported graphic resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900, 1920 x 1080 (HD 1080) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| contrast ratio | 1000:1 |
| Maximum refresh rate | 60 Hz |
| angle of view, horizontal | 178° |
| angle of view, vertical | 178° |
| Number of colors of the display | 16,78 Millionen Farben |
| Response Time (Fast) | 5 ms |
| pixels spacing | 0,2745 x 0,2745 mm |
| pixel density | 92,53 ppi |
| Horizontal scan area | 30 - 83 kHz |
| Vertical scan area | 56 - 76 Hz |
| Visible size (horizontal) | 52,7 cm |
| Visible size (vertical) | 29,6 cm |
| Visible size (diagonal) | 60,5 cm |
| screen size (cm) | 60,47 cm |
| Farbraumstandard | sRGB |
| Farbskala | 100% |
| Design | |
| market positioning | Business |
| Product color | Silber |
| front frame | Schwarz |
| foot color | Silber |
| connections and interfaces | |
| USB-Upstream-Porttyp | USB Typ-C |
| Number of upstream slots | 1 |
| Number of upstream ports USB Type-C | 1 |
| Number of downstream USB-A type slots | 3 |
| Number of USB-C type downstream ports | 1 |
| Number of HDMI ports | 1 |
| HDMI-Version | 1.4 |
| Number of DisplayPort connections | 2 |
| DisplayPorts-Version | 1.4 |
| Type charging port | USB Typ-A |
| Ergonomics | |
| Panel mounting interface | 100 x 100 mm |
| Einstellbare Höhe (max.) | 15 cm |
| Pivot Store | -90 - 90° |
| swivel angle range | -45 - 45° |
| tilt angle range | -5 - 21° |
| energy | |
| Energy efficiency class (SDR) | C |
| Energy efficiency class (HDR) | Nicht verfügbar |
| Energy consumption (SDR) per 1,000 hours | 12 kWh |
| Power consumption (standard operation) | 11,6 W |
| Power consumption (standby) | 0,3 W |
| Power consumption (max.) | 63 W |
| power consumption (off) | 0,3 W |
| Power consumption (PowerSave) | 11,06 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| input current | 1.2 A |
| power supply type | Intern |
| energy efficiency scale | A bis G |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -20 - 60 °C |
| Operating relative humidity | 10 - 80% |
| humidity during storage | 5 - 90% |
| weight and dimensions | |
| Gerätebreite (inkl. Standfuß) | 537,6 mm |
| Gerätetiefe (inkl. Standfuß) | 179,6 mm |
| Gerätehöhe (inkl. Standfuß) | 496 mm |
| Gewicht (inklusive Standfuß) | 5,27 kg |
| Width (without stand) | 537,6 mm |
| Depth (without stand) | 48,5 mm |
| Height (without stand) | 310,7 mm |
| Gewicht (ohne Standfuß) | 3,52 kg |
| Rahmenbreite (Seite) | 5,3 mm |
| Rahmenbreite (oben) | 5,3 mm |
| Rahmenbreite (unten) | 8,95 mm |
| package weight | 7,82 kg |
| CO2-Fußabdruck | |
| Gesamter Kohlendioxid-Fußabdruck (kg of CO2e) | 479 |
| Kohlenstoffemissionen insgesamt, Standardabweichung (kg an CO2e) | 99 |
| Kohlenstoffemissionen, Herstellung (kg an CO2e) | 338,65 |
| Kohlenstoffemissionen, Logistik (kg an CO2e) | 39,1 |
| Kohlenstoffemissionen, Energieverbrauch (kg an CO2e) | 98,6 |
| Kohlenstoffemissionen, Ende der Lebensdauer (kg an CO2e) | 2,53 |
| Kohlenstoffemissionen gesamt, mit/ohne Nutzungsphase(kg an CO2e) | 380,4 |
| PAIA-Version | 1.2.13, 2021 |
| logistic data | |
| Goods tariff number (HS) | 85285210 |
