screen | |
screen size | 60,5 cm (23.8") |
Display resolution | 1920 x 1080 Pixel |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
screen technology | LED |
Panel-Typ | IPS |
Backlight type | W-LED |
brightness (typical) | 300 cd/m² |
reaction time | 4 ms |
Eigenschaft | LowBlue-Modus |
screen shape | Flach |
Supported graphic resolutions | 1920 x 1080 (HD 1080) |
aspect ratio | 16:9 |
contrast ratio | 1000:1 |
Contrast Ratio (dynamic) | 50000000:1 |
Dynamic Contrast Ratio Marketing Label | SmartContrast |
Maximum refresh rate | 75 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,2745 x 0,2745 mm |
pixel density | 93 ppi |
Horizontal scan area | 30 - 85 kHz |
Vertical scan area | 48 - 75 Hz |
Visible size (horizontal) | 52,7 cm |
Visible size (vertical) | 29,6 cm |
Digital horizontal frequency | 30 - 85 kHz |
Digital vertical frequency | 48 - 75 Hz |
screen size (cm) | 60,5 cm |
turbidity rate | 25% |
surface hardness | 3H |
Farbraumstandard | sRGB |
Farbskala | 91% |
sRGB coverage (classic) | 107% |
NTSC coverage (typical) | 91% |
Services | |
Component Video Sync | Separate sync, Sync-on-green (SOG) |
Multimedia | |
number of speakers | 2 |
RMS performance | 2 W |
Design | |
market positioning | Business |
Product color | Schwarz |
front frame | Schwarz |
foot color | Schwarz |
connections and interfaces | |
Number of VGA (D-Sub) connections | 1 |
Number of DVI-D connectors | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 1.4 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.2 |
headphone outputs | 1 |
headphone connection | 3,5 mm |
HDCP-Version | 1.4 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Lock-Type Cable Barrier | Kensington |
height adjustment | 13 cm |
Pivot Store | -90 - 90° |
swivel angle range | -180 - 180° |
tilt angle range | -5 - 25° |
Number of OSD languages | 21 |
LED indicators | Tätigkeit, Stand-by |
energy | |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1,000 hours | 16 kWh |
Power consumption (standard operation) | 13,6 W |
Power consumption (standby) | 0,3 W |
power consumption (off) | 0,3 W |
Power consumption (PowerSave) | 10,4 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
power supply type | Intern |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 20 - 80% |
humidity during storage | 20 - 80% |
operating height | 0 - 3658 m |
storage height | 0 - 12192 m |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 540 mm |
Gerätetiefe (inkl. Standfuß) | 205 mm |
Gerätehöhe (inkl. Standfuß) | 482 mm |
Gewicht (inklusive Standfuß) | 4,83 kg |
Width (without stand) | 540 mm |
Depth (without stand) | 51 mm |
Height (without stand) | 323 mm |
Gewicht (ohne Standfuß) | 2,98 kg |
package weight | 7,91 kg |
packaging type | Box |
scope of delivery | |
Supplied cables | VGA, HDMI, DisplayPort, Audio (3.5 mm), AC |
Included software | SmartControl |
sustainability | |
sustainability certificates | ENERGY STAR, TCO |
Does not contain | PVC/BFR, Quecksilber |
Other functions | |
outer lining type | Texturiert |
Bild-Verbesserung | SmartImage |
Recyclable packaging material | 100% |
Behördliche Zulassung | CB; FCC Class B; ICES-003; CE Mark; TUV/GS; TUV Ergo; CU-EAC; UKRAINIAN; CCC; CEL; CECP; TUV Eye Comfort certified |
Heavy metal free | Hg (Quecksilber) |
Energy efficiency class (old) | E |
Konformitätsbescheinigungen | RoHS |
Mean Time Between Failures (MTBF) | 70000 h |
certification | CB, EPA, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, UKRAINIAN, CCC, CEL, CECP, TUV Eye Comfort certified |
Plastic recycled after use | 85% |
logistic data | |
Goods tariff number (HS) | 85285210 |
