screen | |
screen size | 68,6 cm (27") |
Display resolution | 1920 x 1080 Pixel |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
screen technology | LCD |
Panel-Typ | IPS |
Backlight type | LED |
brightness (typical) | 300 cd/m² |
reaction time | 8 ms |
Eigenschaft | Schnellstartübersicht |
screen shape | Flach |
Supported graphic resolutions | 1920 x 1080 (HD 1080) |
Supported video modes | 480p, 576p, 720p, 1080i, 1080p |
aspect ratio | 16:9 |
contrast ratio | 1000:1 |
Maximum refresh rate | 60 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
Response Time (Fast) | 5 ms |
pixels spacing | 0,2745 x 0,2745 mm |
pixel density | 102 ppi |
Horizontal scan area | 30 - 83 kHz |
Vertical scan area | 50 - 76 Hz |
Visible size (horizontal) | 59,8 cm |
Visible size (vertical) | 33,6 cm |
Visible size (diagonal) | 68,6 cm |
screen size (cm) | 68,6 cm |
color depth | 6 Bit |
sRGB coverage (classic) | 99% |
Services | |
Design | |
market positioning | Business |
Product color | Schwarz |
front frame | Schwarz |
foot color | Silber |
connections and interfaces | |
USB-Hub-Version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
USB-Upstream-Porttyp | USB Typ-B |
Number of upstream slots | 1 |
Number of downstream USB-A type slots | 4 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 1.4 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.2 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
height adjustment | 15 cm |
Pivot Store | -90 - 90° |
swivel angle range | -45 - 45° |
tilt angle range | -5 - 21° |
LED indicators | Leistung |
energy | |
Energy efficiency class (SDR) | D |
Energy efficiency class (HDR) | Nicht verfügbar |
Energy consumption (SDR) per 1,000 hours | 15 kWh |
Power consumption (standard operation) | 15 W |
Power consumption (standby) | 0,2 W |
Power consumption (max.) | 55 W |
power consumption (off) | 0,2 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
power supply type | Intern |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 10 - 80% |
humidity during storage | 5 - 90% |
operating height | 0 - 5000 m |
storage height | 0 - 12192 m |
weight and dimensions | |
Device width (incl. foot) | 609,9 mm |
Device depth (incl. foot) | 190,1 mm |
Device height (incl. foot) | 384,1 mm |
Weight (with stand) | 6,77 kg |
Width (without stand) | 609,9 mm |
Depth (without stand) | 52,1 mm |
Height (without stand) | 359,6 mm |
Weight (without stand) | 4,38 kg |
Rahmenbreite (Seite) | 6,01 mm |
Rahmenbreite (oben) | 5,99 mm |
Rahmenbreite (unten) | 1,73 cm |
scope of delivery | |
Supplied cables | AC, DisplayPort, USB |
sustainability | |
sustainability certificates | ENERGY STAR, EPEAT Gold |
Does not contain | PVC/BFR |
CO2-Fußabdruck | |
Gesamter Kohlendioxid-Fußabdruck (kg of CO2e) | 517 |
Kohlenstoffemissionen insgesamt, Standardabweichung (kg an CO2e) | 99 |
Kohlenstoffemissionen, Herstellung (kg an CO2e) | 339 |
Kohlenstoffemissionen, Logistik (kg an CO2e) | 47 |
Kohlenstoffemissionen, Energieverbrauch (kg an CO2e) | 129 |
Kohlenstoffemissionen, Ende der Lebensdauer (kg an CO2e) | 3 |
Kohlenstoffemissionen gesamt, mit/ohne Nutzungsphase(kg an CO2e) | 388 |
Other functions | |
Heavy metal free | Hg (Quecksilber) |
Konformitätsbescheinigungen | RoHS |
logistic data | |
Goods tariff number (HS) | 85285210 |
