screen | |
screen size | 54,6 cm (21.5") |
Display resolution | 1920 x 1080 Pixel |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
screen technology | LCD |
Panel-Typ | VA |
Eigenschaft | Schnellstartübersicht |
Backlight type | Seiten-LED |
brightness (typical) | 250 cd/m² |
reaction time | 8 ms |
Messungsart der Reaktionszeit | GTG (Gray to Gray) |
screen shape | Flach |
Supported graphic resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1600 x 900, 1920 x 1080 (HD 1080) |
Supported video modes | 480p, 576p, 720p, 1080p |
contrast ratio | 3000:1 |
Maximum refresh rate | 100 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
Response Time (Fast) | 5 ms |
pixels spacing | 0,2493 x 0,241 mm |
pixel density | 102 ppi |
Horizontal scan area | 30 - 82 kHz |
Vertical scan area | 50 - 76 Hz |
Visible size (horizontal) | 47,9 cm |
Visible size (vertical) | 26 cm |
Digital horizontal frequency | 30 - 111 kHz |
Digital vertical frequency | 50 - 100 Hz |
surface hardness | 3H |
NTSC coverage (typical) | 72% |
Services | |
Design | |
market positioning | Büro |
Product color | Schwarz |
front frame | Schwarz |
foot color | Schwarz |
connections and interfaces | |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
HDCP-Version | 1.4 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Lock-Type Cable Barrier | Kensington |
tilt angle range | -5 - 21° |
energy | |
Energy efficiency class (SDR) | D |
Energy efficiency class (HDR) | Nicht verfügbar |
Energy consumption (SDR) per 1,000 hours | 12 kWh |
Power consumption (standard operation) | 11,7 W |
Power consumption (standby) | 0,3 W |
Power consumption (max.) | 20,7 W |
power consumption (off) | 0,3 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
input current | 1 A |
power supply type | Intern |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 10 - 80% |
humidity during storage | 5 - 90% |
operating height | 0 - 5000 m |
storage height | 5000 - 12192 m |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 492,9 mm |
Gerätetiefe (inkl. Standfuß) | 211,8 mm |
Gerätehöhe (inkl. Standfuß) | 395,8 mm |
Gewicht (inklusive Standfuß) | 2,67 kg |
Width (without stand) | 492,9 mm |
Depth (without stand) | 44,9 mm |
Height (without stand) | 286,5 mm |
Gewicht (ohne Standfuß) | 2,23 kg |
Rahmenbreite (Seite) | 7,05 mm |
Rahmenbreite (oben) | 7,05 mm |
Rahmenbreite (unten) | 1,85 cm |
package weight | 4,38 kg |
scope of delivery | |
Supplied cables | AC, HDMI |
HDMI cable length | 1,8 m |
sustainability | |
sustainability certificates | ENERGY STAR |
Does not contain | PVC/BFR |
