screen | |
screen size | 54,6 cm (21.5") |
Display resolution | 1920 x 1080 Pixel |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
screen technology | LED |
Panel-Typ | TFT/IPS |
brightness (typical) | 500 cd/m² |
reaction time | 5 ms |
Eigenschaft | DICOM |
screen shape | Flach |
contrast ratio | 1000:1 |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,248 x 0,248 mm |
Digital horizontal frequency | 31 - 84 kHz |
Digital vertical frequency | 56 - 75 Hz |
turbidity rate | 25% |
surface hardness | 3H |
color depth | 8 Bit |
Multimedia | |
number of speakers | 2 |
RMS performance | 6 W |
Design | |
market positioning | Medizinisch |
Product color | Weiß |
Glasdicke | 1,8 mm |
connections and interfaces | |
Lot of USB 2.0 ports | 1 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 1.4 |
Number of DisplayPort connections | 1 |
Ergonomics | |
Panel mounting interface | 100 x 100,300 x 100 mm |
Lock-Type Cable Barrier | Kensington |
energy | |
Energy efficiency class (SDR) | E |
Energy efficiency class (HDR) | Nicht verfügbar |
Energy consumption (SDR) per 1,000 hours | 15 kWh |
Power consumption (standard operation) | 15 W |
Power consumption (standby) | 0,5 W |
Power consumption (max.) | 30 W |
power consumption (off) | 0,3 W |
power supply output voltage | 12 V |
power supply type | Extern |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
weight and dimensions | |
Width (without stand) | 528,4 mm |
Depth (without stand) | 48,2 mm |
Height (without stand) | 325,5 mm |
Gewicht (ohne Standfuß) | 4,7 kg |
package weight | 6,45 kg |
scope of delivery | |
Supplied cables | AC, HDMI |
Other functions | |
International degree of protection (IP code) | IP65 |
protective function | Staubresistent, Wasserdicht |
IK-Kodex | IK07 |
Delta E | 2 |
Übertragungsrate | 97% |
Konformitätsbescheinigungen | CE, EAC, Eidgenössische Kommunikationskommission (FCC), Niederspannungsrichtlinie (LVD), REACH, RoHS, WEEE |
