| screen | |
| screen size | 54,6 cm (21.5") |
| Display resolution | 1920 x 1080 Pixel |
| HD-Typ | Full HD |
| Native Aspect Ratio | 16:9 |
| screen technology | LED |
| Panel-Typ | TFT/IPS |
| brightness (typical) | 500 cd/m² |
| reaction time | 5 ms |
| Eigenschaft | DICOM |
| screen shape | Flach |
| contrast ratio | 1000:1 |
| angle of view, horizontal | 178° |
| angle of view, vertical | 178° |
| Number of colors of the display | 16,7 Millionen Farben |
| pixels spacing | 0,248 x 0,248 mm |
| Digital horizontal frequency | 31 - 84 kHz |
| Digital vertical frequency | 56 - 75 Hz |
| turbidity rate | 25% |
| surface hardness | 3H |
| color depth | 8 Bit |
| Multimedia | |
| number of speakers | 2 |
| RMS performance | 6 W |
| Design | |
| market positioning | Medizinisch |
| Product color | Weiß |
| Glasdicke | 1,8 mm |
| connections and interfaces | |
| Lot of USB 2.0 ports | 1 |
| Number of VGA (D-Sub) connections | 1 |
| Number of HDMI ports | 1 |
| HDMI-Version | 1.4 |
| Number of DisplayPort connections | 1 |
| Ergonomics | |
| Panel mounting interface | 100 x 100,300 x 100 mm |
| Lock-Type Cable Barrier | Kensington |
| energy | |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Nicht verfügbar |
| Energy consumption (SDR) per 1,000 hours | 15 kWh |
| Power consumption (standard operation) | 15 W |
| Power consumption (standby) | 0,5 W |
| Power consumption (max.) | 30 W |
| power consumption (off) | 0,3 W |
| power supply output voltage | 12 V |
| power supply type | Extern |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Storage temperature range | -20 - 60 °C |
| Operating relative humidity | 10 - 90% |
| humidity during storage | 5 - 95% |
| weight and dimensions | |
| Width (without stand) | 528,4 mm |
| Depth (without stand) | 48,2 mm |
| Height (without stand) | 325,5 mm |
| Gewicht (ohne Standfuß) | 4,7 kg |
| package weight | 6,45 kg |
| scope of delivery | |
| Supplied cables | AC, HDMI |
| Other functions | |
| International degree of protection (IP code) | IP65 |
| protective function | Staubresistent, Wasserdicht |
| IK-Kodex | IK07 |
| Delta E | 2 |
| Übertragungsrate | 97% |
| Konformitätsbescheinigungen | CE, EAC, Eidgenössische Kommunikationskommission (FCC), Niederspannungsrichtlinie (LVD), REACH, RoHS, WEEE |
