screen | |
screen size | 57,1 cm (22.5") |
Display resolution | 1920 x 1200 Pixel |
HD-Typ | WUXGA |
Native Aspect Ratio | 16:10 |
screen technology | LED |
Panel-Typ | IPS |
Backlight type | LED |
brightness (typical) | 250 cd/m² |
reaction time | 5 ms |
screen shape | Flach |
Supported graphic resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
contrast ratio | 1000:1 |
Maximum refresh rate | 60 Hz |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,78 Millionen Farben |
pixels spacing | 0,254 x 0,248 mm |
pixel density | 101 ppi |
Horizontal scan area | 31 - 75,5 kHz |
Vertical scan area | 59 - 61 Hz |
Visible size (horizontal) | 48,8 cm |
Visible size (vertical) | 29,7 cm |
Visible size (diagonal) | 57,2 cm |
Farbraumstandard | sRGB |
Services | |
Eigenschaft | Nachhaltigkeitskonformität |
Multimedia | |
number of speakers | 2 |
RMS performance | 2 W |
Design | |
market positioning | Business |
Product color | Weiß |
connections and interfaces | |
USB-Hub-Version | 3.2 Gen 1 (3.1 Gen 1) |
USB-Upstream-Porttyp | USB Typ-B |
Number of upstream slots | 1 |
Number of downstream USB-A type slots | 2 |
Number of VGA (D-Sub) connections | 1 |
Number of DisplayPort connections | 1 |
headphone connection | 3,5 mm |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Einstellbare Höhe (max.) | 14 cm |
Pivot Store | -90 - 90° |
swivel angle range | 0 - 344° |
tilt angle range | -5 - 35° |
menu languages | Vereinfachtes Chinesisch, Traditionelles Chinesisch, Deutsch, Englisch, Spanisch, Französisch, Italienisch, Japanisch, Schwedisch |
energy | |
Energy efficiency class (SDR) | C |
Energy consumption (SDR) per 1,000 hours | 11 kWh |
Power consumption (standard operation) | 10,5 W |
Power consumption (standby) | 0,5 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 5 - 35 °C |
Operating relative humidity | 20 - 80% |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 499 mm |
Gerätetiefe (inkl. Standfuß) | 233 mm |
Gerätehöhe (inkl. Standfuß) | 333,9 mm |
Gewicht (inklusive Standfuß) | 5,5 kg |
Width (without stand) | 499 mm |
Depth (without stand) | 53,6 mm |
Height (without stand) | 321,3 mm |
Gewicht (ohne Standfuß) | 3,4 kg |
scope of delivery | |
Supplied cables | AC, DisplayPort, USB |
sustainability | |
sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO |
Other functions | |
Konformitätsbescheinigungen | BIS, BSMI, CB, CCC, CE, China RoHS, EAC, Eidgenössische Kommunikationskommission (FCC), ICES, PSE, RCM, RoHS, cTUVus, VCCI, WEEE |
logistic data | |
Goods tariff number (HS) | 85285210 |
