screen | |
Panel-Typ | IPS |
screen size | 2,18 m (86") |
screen technology | LED |
Display resolution | 3840 x 2160 Pixel |
brightness | 800 cd/m² |
HD-Typ | 4K Ultra HD |
Native Aspect Ratio | 16:9 |
reaction time | 8 ms |
contrast ratio | 1200:1 |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 1,07 Milliarden Farben |
pixels spacing | 0,315 x 0,315 mm |
Active display area (W x H) | 1209,6 x 680,4 mm |
screen size (cm) | 217 cm |
Horizontal scan area | 28 - 160 kHz |
Wiederholfrequenz | 60 Hz |
turbidity rate | 1% |
RGB color space | NTSC |
connections and interfaces | |
Number of HDMI ports | 2 |
HDMI-Version | 2.0 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.2 |
Eigenschaft | Fernbedienung enthalten |
Number of USB ports | 2 |
USB-Version | 2.0 |
Number of Ethernet LAN ports (RJ-45) | 1 |
WLAN-Standards | Wi-Fi 5 (802.11ac) |
Audio input (L, R) | 1 |
Audio | |
Number of built-in speakers | 2 |
RMS performance | 20 W |
Design | |
product design | Kiosk-Design |
alignment | Horizontal/Vertikal |
Product color | Schwarz |
Panel mounting interface | 600 x 400 mm |
Rahmenbreite (unten) | 1,62 cm |
Rahmenbreite (Seite) | 1,6 cm |
Rahmenbreite (oben) | 1,62 cm |
Lünettenfarbe | black |
Services | |
purpose | Kommerziell |
Number of OSD languages | 8 |
menu languages | Vereinfachtes Chinesisch, Tschechisch, Deutsch, Englisch, Spanisch, Französisch, Italienisch, Japanisch, Polnisch, Russisch |
Operating times (hours/days) | 24/7 |
HDCP-Version | 2.2 |
Mean Time Between Failures (MTBF) | 50000 h |
energy | |
Power consumption (standard operation) | 159 W |
Power consumption (standby) | 0,5 W |
power consumption (off) | 0,3 W |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1,000 hours | 159 kWh |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
energy efficiency scale | A bis G |
computer system | |
processor manufacturer | ARM |
processor family | ARM Cortex |
processor architecture | ARM Cortex-A53+Cortex-A73 |
number of CPU cores | 8 |
storage capacity | 4 GB |
Eingebautes Grafikkartenmodell | ARM Mali-G52 |
Internal storage capacity | 32 GB |
Installed operating system | Android 11 |
weight and dimensions | |
Displaybreite | 1927 mm |
display depth | 57 mm |
display height | 1098,5 mm |
Display weight | 49 kg |
package weight | 64 kg |
scope of delivery | |
Supplied cables | HDMI, Leistung, RS-232 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | -20 - 60% |
