screen | |
Panel-Typ | IPS |
LED backlight type | Direct-LED |
screen size | 60,5 cm (23.8") |
Display resolution | 1920 x 1080 Pixel |
brightness | 250 cd/m² |
HD-Typ | 4K Ultra HD |
Eigenschaft | Plug & Play |
Touchscreen Technology | Projizierts Kapazitivsystem |
Number of simultaneous touchpoints | 10 |
Native Aspect Ratio | 16:9 |
reaction time | 14 ms |
contrast ratio | 1000:1 |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,275 x 0,275 mm |
Active display area (W x H) | 527 x 296,5 mm |
screen size (cm) | 60,5 cm |
Lebensdauer des Panels | 50000 h |
Horizontal scan area | 31 - 83 kHz |
surface hardness | 3H |
connections and interfaces | |
Number of HDMI ports | 1 |
Number of HDMI input interfaces | 1 |
VGA (D-Sub) input connectors | 1 |
Number of USB 2.0 ports type B | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 1 |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Audio | |
Number of built-in speakers | 2 |
RMS performance | 5 W |
Design | |
product design | Digital Signage Flachbildschirm |
Unterstützte Positionierung | Drinnen |
Product color | Schwarz |
Panel mounting interface | 100 x 100 mm |
Services | |
purpose | Kommerziell |
Operating times (hours/days) | 24/7 |
Mean Time Between Failures (MTBF) | 50000 h |
energy | |
Power consumption (standard operation) | 19 W |
Power consumption (standby) | 0,5 W |
power consumption (off) | 0,3 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
computer system | |
processor manufacturer | Rockchip |
processor family | ARM Rockchip |
processor | RK3399 |
processor clock speed | 1,8 GHz |
number of CPU cores | 2 |
storage capacity | 4 GB |
Internal storage capacity | 32 GB |
Installed operating system | Android |
version of the operating system | 12 |
weight and dimensions | |
Displaybreite | 549,5 mm |
display depth | 28 mm |
display height | 336 mm |
Display weight | 4,23 kg |
package weight | 6,15 kg |
scope of delivery | |
Anzahl der Stylus-Stifte | 4 |
Supplied cables | HDMI, Leistung, USB |
certificates | |
certification | CE, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
features | |
base color | Schwarz |
base material | Metall |
Technical details | |
OPS-Steckplatz | 1 |
Other functions | |
Bluetooth-Version | 5.2 |
power supply type | Intern |
