23.8 " | 2560 x 1440 pixels | Quad HD | 16:9 | LED | IPS | 6 ms | Flat | Contrast 1000:1 | Maximum refresh rate 75 Hz | 1xHDMI ports quantity | 1xDisplayPorts quantity | VESA Yes
Description | The 2560*1440 resolution produces clearer and more vivid picturesIPS panel for wide viewing angles with 3-sided frameless design178°H/178°V extra-wide viewing angle for overall viewing performanceWide color gamut:99% sRGB, 120% NTSC, 98% DCI-P3Rich interfaces, 65W type-C can support reverse charging6ms fast response time with no image blurring or ghostingSupporting PIP/PBP to display the screens of two devices on the display simultaneouslyThe angle can be adjusted to meet different needs |
Summary | Dahua Technology LM24-P301A. Display diagonal: 60.5 cm (23.8"), Display resolution: 2560 x 1440 pixels, HD type: Quad HD, Display technology: LED, Response time: 6 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub. VESA mounting, Height adjustment. Product colour: Black |
Vendor Homepage | https://display.dahuasecurity.com/consumer/en/products/productDetail?product_id=115227 |
Category Code | LC3 |
Unit Box Height | 0.395 |
Unit Box Length | 0.785 |
Unit Box Width | 0.125 |
Adobe RGB coverage | 93 % |
Aspect Ratio | 16:9 |
Backlight type | Edge LED |
Colour gamut | 98 % |
Colour gamut standard | DCI-P3 |
Contrast ratio (typical) | 1000:1 |
Display brightness (typical) | 320 cd/m² |
Display diagonal | 23.8 " |
Display resolution | 2560 x 1440 pixels |
Display Technology | LED |
HD type | Quad HD |
Maximum refresh rate | 75 Hz |
Native Aspect Ratio | 16:9 |
NTSC coverage (typical) | 102 % |
Panel type | IPS |
Response time | 6 ms |
Screen shape | Flat |
sRGB coverage (typical) | 99 % |
Supported graphics resolutions | 2560 x 1440 |
Touchscreen | No |
Viewing angle, horizontal | 178 ° |
Viewing angle, vertical | 178 ° |
Built-in camera | No |
Built-in speaker(s) | No |
Detachable stand | Yes |
Feet colour | Black |
Market positioning | Business |
Product colour | Black |
AC (power) in | Yes |
Audio output | Yes |
Built-in USB hub | Yes |
DisplayPort version | 1.4 |
DisplayPorts quantity | 1 |
HDMI | Yes |
HDMI ports quantity | 1 |
HDMI version | 2.1 |
Headphone out | No |
USB Power Delivery (USB PD) | Yes |
USB Power Delivery up to | 65 W |
USB Type-C downstream ports quantity | 1 |
Adjustable height (max) | 125 mm |
HEIGHT ADJUSTMENT | Yes |
On Screen Display (OSD) | Yes |
Panel mounting interface | 75 x 75 mm |
Picture-in-Picture | Yes |
Pivot | Yes |
corner swivel | 0 - 90 ° |
Swivel angle range | -45 - 45 ° |
Swivelling | Yes |
Tilt adjustment | Yes |
Tilt angle range | -5 - 20 ° |
VESA mounting | Yes |
Wall mountable | Yes |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Energy consumption (SDR) per 1000 hours | 20 kWh |
Energy efficiency class (SDR) | F |
Energy efficiency scale | A to G |
European Product Registry for Energy Labelling (EPREL) code | 1363937 |
Input current | 2 A |
Power consumption (max) | 130 W |
Power consumption (standby) | 0.5 W |
Power consumption (typical) | 35 W |
Power supply type | Internal |
Operating relative humidity (H-H) | 10 - 85 % |
Operating temperature (T-T) | 0 - 40 °C |
Depth (without stand) | 53.25 mm |
Height (without stand) | 324.46 mm |
Weight (without stand) | 5700 g |
Width (without stand) | 539.6 mm |
Package depth | 127 mm |
Package height | 397 mm |
Package Type | Box |
PACKAGE WEIGHT | 8200 g |
Package width | 779 mm |
CABLES INCLUDED | AC/HDMI |
HDMI cable length | 1.5 m |
Stand included | Yes |
Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1363937/fiches?language=EN |
Energy Efficiency Class | F |
EPREL Registration Number | 1363937 |
EPREL Version Number | 1 |
Model | DHI-LM24-P301A |
Unit Calculated Volume | 0.03876 cubm |
Product Net Weight | 5.7 kg |
Unit Calculated Weight | 7.4 kg |
