23.6 " | 1920 x 1080 pixels | Full HD | 16:9 | LED | VA | 1 ms | Curved | Contrast 3000:1 | Maximum refresh rate 165 Hz | 2xHDMI ports quantity | 1xDisplayPorts quantity | Headphone out Yes | VESA Yes
Description | Comfortable 1500R exquisite curvature, close to the natural look and feel of the human eye, bringing immersive visual enjoymentThe 1920*1080 resolution produces clearer and more vivid picturesVA panel for wide viewing angles with 3-sided frameless designWide color gamut, 99% sRGB, 83% NTSC, 85% DCI-P3, 80% Adobe RGB. It meets the designer's demand of image textureThe 165Hz high refresh rate enables you to aim at the target more quickly, eliminates picture lagging, and helps you to aim at the target fasterAdaptive sync can effectively solve picture lagging and tearing |
Summary | Dahua Technology DHI-LM24-E230C. Display diagonal: 59.9 cm (23.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 1 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black |
Vendor Homepage | https://www.dahuasecurity.com/la/products/All-Products/Display--Control/Monitors/Gaming-Series/LM24-E230C |
Category Code | LC3 |
CnCode | 85285210 |
Unit Box Height | 0.42 |
Unit Box Length | 0.63 |
Unit Box Width | 0.15 |
Adobe RGB coverage | 80 % |
Backlight type | Edge LED |
Contrast ratio (typical) | 3000:1 |
Display brightness (typical) | 250 cd/m² |
Display diagonal | 23.6 " |
Display resolution | 1920 x 1080 pixels |
Display Technology | LED |
HD type | Full HD |
Maximum refresh rate | 165 Hz |
Native Aspect Ratio | 16:9 |
NTSC coverage (typical) | 83 % |
Panel type | VA |
Response time | 1 ms |
Screen curvature rating | 1500R |
Screen shape | Curved |
sRGB coverage (typical) | 99 % |
Touchscreen | No |
Viewing angle, horizontal | 178 ° |
Viewing angle, vertical | 178 ° |
Built-in camera | No |
Built-in speaker(s) | No |
Detachable stand | Yes |
Frameless design | Yes |
Market positioning | Gaming |
Product colour | Black |
Built-in USB hub | No |
DC-in jack | Yes |
DisplayPort version | 1.2 |
DisplayPorts quantity | 1 |
HDMI | Yes |
HDMI ports quantity | 2 |
HDMI version | 1.4 |
Headphone out | Yes |
Headphone outputs | 1 |
HEIGHT ADJUSTMENT | No |
Panel mounting interface | 75 x 75 mm |
Pivot | No |
Swivelling | No |
Tilt adjustment | Yes |
Tilt angle range | -5 - 15 ° |
VESA mounting | Yes |
Wall mountable | Yes |
AC adapter output voltage | 12 V |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Energy consumption (SDR) per 1000 hours | 17 kWh |
Energy efficiency class (SDR) | E |
Energy efficiency scale | A to G |
European Product Registry for Energy Labelling (EPREL) code | 1536828 |
Power consumption (max) | 35 W |
Power consumption (standby) | 0.5 W |
Power consumption (typical) | 24 W |
Power supply type | External |
Operating relative humidity (H-H) | 10 - 85 % |
Operating temperature (T-T) | 0 - 40 °C |
Depth (without stand) | 73.96 mm |
Height (without stand) | 333.54 mm |
Weight (with stand) | 3200 g |
Width (without stand) | 537.86 mm |
Package depth | 149 mm |
Package height | 407 mm |
PACKAGE WEIGHT | 4900 g |
Package width | 630 mm |
CABLES INCLUDED | DisplayPort |
Power adapter included | Yes |
Stand included | Yes |
Data Sheet (Link) | https://eprel.ec.europa.eu/api/product/1536828/fiches?language=EN |
Energy Efficiency Class | E |
EPREL Registration Number | 1536828 |
EPREL Version Number | 1 |
Unit Calculated Volume | 0.03969 cubm |
Product Net Weight | 3.2 kg |
Unit Calculated Weight | 4.7 kg |
