screen | |
Panel-Typ | IPS |
screen size | 81,3 cm (32") |
screen technology | LCD |
Display resolution | 1920 x 1080 Pixel |
brightness | 500 cd/m² |
HD-Typ | Full HD |
Native Aspect Ratio | 16:9 |
reaction time | 8 ms |
contrast ratio | 1200:1 |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,364 x 0,364 mm |
Active display area (W x H) | 698,4 x 392,85 mm |
screen size (cm) | 80 cm |
Maximum Frame Rate | 60 fps |
Horizontal scan area | 28 - 160 kHz |
turbidity rate | 25% |
RGB color space | sRGB |
connections and interfaces | |
Number of HDMI ports | 2 |
HDMI-Version | 2.0 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.2 |
Eigenschaft | Schnellstartübersicht |
Number of USB ports | 2 |
USB-Version | 2.0 |
Number of Ethernet LAN ports (RJ-45) | 1 |
WLAN-Standards | Wi-Fi 5 (802.11ac) |
Audio | |
Number of built-in speakers | 2 |
RMS performance | 20 W |
Design | |
product design | Digital Signage Flachbildschirm |
Unterstützte Positionierung | Drinnen |
alignment | Horizontal/Vertikal |
Product color | Schwarz |
Panel mounting interface | 200 x 200 mm |
Rahmenbreite (unten) | 1,19 cm |
Rahmenbreite (Seite) | 1,19 cm |
Rahmenbreite (oben) | 1,19 cm |
Services | |
purpose | Universal |
Number of OSD languages | 11 |
menu languages | Tschechisch, Deutsch, Niederländisch, Englisch, Spanisch, Französisch, Italienisch, Japanisch, Polnisch, Russisch |
Operating times (hours/days) | 24/7 |
HDCP-Version | 2.2 |
Mean Time Between Failures (MTBF) | 44000 h |
energy | |
Power consumption (standard operation) | 46 W |
Power consumption (standby) | 0,5 W |
power consumption (off) | 0,3 W |
Energy efficiency class (SDR) | G |
Energy consumption (SDR) per 1,000 hours | 46 kWh |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
energy efficiency scale | A bis G |
computer system | |
processor manufacturer | ARM |
processor family | ARM Cortex |
processor architecture | ARM Cortex-A53+Cortex-A73 |
number of CPU cores | 4 |
storage capacity | 4 GB |
Internal storage capacity | 32 GB |
Installed operating system | Android 11 |
weight and dimensions | |
Displaybreite | 725,5 mm |
display depth | 54 mm |
display height | 421,8 mm |
Display weight | 5,2 kg |
scope of delivery | |
Supplied cables | AC, HDMI, RS-232 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
certificates | |
certification | CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
logistic data | |
Goods tariff number (HS) | 85285210 |
Technical details | |
Konformitätsbescheinigungen | RoHS |
Other functions | |
housing material | Metall |
