screen | |
Panel-Typ | VA |
Eigenschaft | Schnellstartübersicht |
screen size | 80 cm (31.5") |
screen technology | LCD |
Display resolution | 1920 x 1080 Pixel |
brightness | 350 cd/m² |
HD-Typ | Full HD |
reaction time | 5 ms |
contrast ratio | 4000:1 |
angle of view, horizontal | 178° |
angle of view, vertical | 178° |
Number of colors of the display | 16,7 Millionen Farben |
pixels spacing | 0,364 x 0,364 mm |
Horizontal scan area | 28 - 92 kHz |
Vertical scan area | 48 - 85 Hz |
turbidity rate | 2% |
surface hardness | 3H |
connections and interfaces | |
Number of HDMI ports | 3 |
HDMI-Version | 2.0 |
Number of HDMI input interfaces | 3 |
VGA (D-Sub) input connectors | 1 |
Number of USB ports | 1 |
USB-Version | 2.0 |
Number of Ethernet LAN ports (RJ-45) | 1 |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Audio (L,R) out | 1 |
Remote control (IR) output | 1 |
Audio | |
Number of built-in speakers | 2 |
RMS performance | 20 W |
Design | |
product design | Digital Signage Flachbildschirm |
Unterstützte Positionierung | Drinnen |
alignment | Senkrecht |
Product color | Schwarz |
Panel mounting interface | 100 x 100,200 x 200 mm |
Services | |
purpose | Universal |
Operating times (hours/days) | 16/7 |
energy | |
Power consumption (standard operation) | 42 W |
Power consumption (standby) | 0,5 W |
power consumption (off) | 0,3 W |
Energy efficiency class (SDR) | G |
Energy consumption (SDR) per 1,000 hours | 42 kWh |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
weight and dimensions | |
Displaybreite | 726,5 mm |
display depth | 65,1 mm |
display height | 425,4 mm |
Display weight | 5,7 kg |
package weight | 7,8 kg |
scope of delivery | |
Supplied cables | AC, HDMI |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 20 - 80% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 10 - 90% |
certificates | |
certification | FCC, CE, LVD, UKCA, WEEE, RoHS, REACH, EAC, ICES-003 (Issue 7) |
Other functions | |
RS-232 Eingangs-Ports | 1 |
