screen | |
screen size | 43,2 cm (17") |
Display resolution | 1280 x 1024 Pixel |
HD-Typ | SXGA |
Native Aspect Ratio | 5:4 |
screen technology | LCD |
Panel-Typ | TN |
Backlight type | LED |
brightness (typical) | 250 cd/m² |
reaction time | 5 ms |
screen shape | Flach |
Supported graphic resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA) |
aspect ratio | 5:4 |
contrast ratio | 1000:1 |
Maximum refresh rate | 60 Hz |
angle of view, horizontal | 170° |
angle of view, vertical | 160° |
Number of colors of the display | 16,78 Millionen Farben |
pixels spacing | 0,264 x 0,264 mm |
Horizontal scan area | 30 - 81 kHz |
Vertical scan area | 56 - 76 Hz |
Visible size (horizontal) | 33,8 cm |
Visible size (vertical) | 27 cm |
Visible size (diagonal) | 43,2 cm |
Eigenschaft | Dell Display Manager (DDM)-kompatibel |
Farbskala | 85% |
Design | |
market positioning | Business |
Product color | Schwarz |
foot color | Schwarz |
connections and interfaces | |
Number of VGA (D-Sub) connections | 1 |
Number of DisplayPort connections | 1 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Lock-Type Cable Barrier | Kensington |
tilt angle range | -5,5 - 22° |
energy | |
Energy efficiency class (SDR) | D |
Energy efficiency class (HDR) | Nicht verfügbar |
Energy consumption (SDR) per 1,000 hours | 9 kWh |
Power consumption (standard operation) | 9 W |
Power consumption (standby) | 0,2 W |
Power consumption (max.) | 14 W |
power consumption (off) | 0,2 W |
AC input voltage | 120 - 230 V |
AC input frequency | 50 - 60 Hz |
input current | 1.5 A |
power supply type | Intern |
energy efficiency scale | A bis G |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -20 - 60 °C |
Operating relative humidity | 10 - 80% |
humidity during storage | 5 - 90% |
operating height | 0 - 5000 m |
storage height | 0 - 12192 m |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 374,5 mm |
Gerätetiefe (inkl. Standfuß) | 165,5 mm |
Gerätehöhe (inkl. Standfuß) | 389,5 mm |
Gewicht (inklusive Standfuß) | 2,42 kg |
Width (without stand) | 374,5 mm |
Depth (without stand) | 46,5 mm |
Height (without stand) | 306,9 mm |
Gewicht (ohne Standfuß) | 2,08 kg |
package weight | 3,69 kg |
packaging type | Box |
scope of delivery | |
Supplied cables | AC, VGA |
sustainability | |
sustainability certificates | EPEAT Gold, ENERGY STAR |
CO2-Fußabdruck | |
Gesamter Kohlendioxid-Fußabdruck (kg of CO2e) | 335 |
Kohlenstoffemissionen insgesamt, Standardabweichung (kg an CO2e) | 66 |
Kohlenstoffemissionen, Herstellung (kg an CO2e) | 302 |
Kohlenstoffemissionen, Logistik (kg an CO2e) | 27 |
Kohlenstoffemissionen, Energieverbrauch (kg an CO2e) | 124 |
Kohlenstoffemissionen, Ende der Lebensdauer (kg an CO2e) | 2 |
Kohlenstoffemissionen gesamt, mit/ohne Nutzungsphase(kg an CO2e) | 330 |
PAIA-Version | 9/5/2018 |
Other functions | |
Konformitätsbescheinigungen | RoHS |
Dell E-Value Code | E1715S |
certification | CEL, TCO, VESA EDID |
brand properties | |
logistic data | |
Goods tariff number (HS) | 85285210 |
