Projector | |
screen capacity | 762 - 7620 mm (30 - 300") |
projection distance | 0,8 - 12,9 m |
projector brightness | 6200 ANSI Lumen |
projection technology | 3LCD |
native resolution of the projector | WUXGA (1920x1200) |
contrast ratio | 600000:1 |
Native Aspect Ratio | 16:10 |
Trapezoidal correction, horizontal | -30 - 30° |
Trapezoidal correction, vertical | -30 - 30° |
light source | |
Light source type | Laser |
life of the light source | 20000 h |
lens | |
Focus | Manuell |
focal range | 17.2 - 27.7 mm |
aperture range (FF) | 1,5 - 2,1 |
Eigenschaft | Betriebsanleitung |
Zoom type | Manuell |
zoom ratio | 1.6:1 |
Horizontal Lens Fluctuation Range | -29 - 29% |
Vertical Lens Fluctuation Range | 0 - 60% |
Video | |
Analoges Signalformatsystem | NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM |
Supported graphic resolutions | 1920 x 1200 (WUXGA), 3840 x 2160 |
connections and interfaces | |
HDMI connector type | Volle Größe |
Typ Serviceport | USB Typ-B |
Number of USB 2.0 ports | 1 |
Lot of USB 2.0 ports | 2 |
Number of USB 2.0 ports type B | 1 |
Audio input (L, R) | 1 |
Audio (L,R) out | 1 |
Serial interface | RJ-45, RS-232 |
Number of VGA (D-Sub) connections | 1 |
Number of HDMI ports | 2 |
network | |
Number of Ethernet LAN ports (RJ-45) | 1 |
features | |
Noise level (energy saving mode) | 22 dB |
Projection modes | Zimmerdecke, Vorderseite |
Number of OSD languages | 30 |
noise level | 27 dB |
certification | CE; EAC; ErP; RoHS; TUEV, TÜV |
Multimedia | |
RMS performance | 20 W |
Number of built-in speakers | 1 |
Design | |
market positioning | Heimkino |
product type | Standard Throw-Projektor |
Product color | Weiß |
placement | Zimmerdecke, Desktop |
Lock-Type Cable Barrier | Kensington |
energy | |
energy source | AC |
Power consumption (standard operation) | 318 W |
Power consumption (standby) | 0,3 W |
Consumption (energy saving mode) | 237 W |
AC input voltage | 100-240 V |
AC input frequency | 50-60 Hz |
operating conditions | |
operating temperatur | 5 - 40 °C |
Storage temperature range | -10 - 50 °C |
Operating relative humidity | 20 - 80% |
humidity during storage | 20 - 80% |
weight and dimensions | |
broad | 480 mm |
depth | 407 mm |
height | 122 mm |
Weight | 9,7 kg |
scope of delivery | |
remote control type | IR |
Supplied cables | AC |
logistic data | |
quantity per pack | 1 Stück(e) |
