Sustainability certificates | TCO |
Country of origin | Philippines |
Interactive | No |
HDCP | Yes |
Noise level (economic mode) | 23 dB |
PASSWORD PROTECTION | Yes |
Noise level | 31 dB |
Market positioning | Presentation |
Placement | Ceiling, Desktop |
Product colour | White |
Product Type | Standard throw projector |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Power consumption (economy mode) | 223 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100-240 V |
Power consumption (typical) | 293 W |
Power consumption (standby) | 0.3 W |
Power source | AC |
Storage temperature (T-T) | -10 - 60 °C |
Storage relative humidity (H-H) | 10 - 90% |
Operating relative humidity (H-H) | 20 - 80% |
Weight | 8.2 kg |
Width | 440 mm |
Package height | 210 mm |
Package depth | 565 mm |
PACKAGE WEIGHT | 12 kg |
Depth | 339 mm |
Height | 136 mm |
Package width | 540 mm |
Wi-Fi standards | 802.11g |
SMART TV | No |
Ethernet LAN (RJ-45) ports | 1 |
Ethernet LAN | Yes |
Miracast | Yes |
Wi-Fi | Yes |
Remote control included | Yes |
WLAN adapter included | Yes |
Manual | Yes |
CABLES INCLUDED | AC |
Warranty card | Yes |
Batteries Included | Yes |
Built-in Display | No |
Software support | via: Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol |
Built-in speaker(s) | Yes |
Number of built-in speakers | 1 |
RMS rated power | 10 W |
Card reader integrated | No |
VGA (D-Sub) ports quantity | 2 |
HDMI ports quantity | 3 |
AC (power) in | Yes |
DVI port | No |
HDBaseT port | Yes |
Serial interface type | RS-232C |
PC Audio out | Yes |
USB 2.0 ports quantity | 2 |
HDMI connector type | Full-size |
USB 2.0 Type-B ports quantity | 1 |
PC Audio in | Yes |
Supported network protocols | HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
Harmonized System (HS) code | 85286200 |
Quantity per pack | 1 pc(s) |
Video processing | 10 bit |
FULL HD | Yes |
Video colour modes | DICOM simulation mode |
Focal length range | 20 - 31.8 mm |
Focus | Manual |
Zoom type | Manual |
Horizontal lens shift range | -20 - 20% |
Aperture range (F-F) | 1.5 - 1.7 |
Zoom capability | Yes |
Vertical lens shift range | -50 - 50% |
Throw Ratio | 1.35 - 2.2:1 |
Zoom ratio | 1.6:1 |
Keystone correction, vertical | -30 - 30° |
Number of colours | 1.07 billion colours |
Contrast ratio (typical) | 2500000:1 |
Projection distance | 1.44 - 23.84 m |
Projection distance (wide) | 1.4 - 14.8 m |
Projector brightness (economic mode) | 3640 ANSI lumens |
Smart projector | No |
Keystone correction, horizontal | -30 - 30° |
Native Aspect Ratio | 16:10 |
Projector brightness | 5200 ANSI lumens |
Screen size compatibility | 1270 - 12700 mm (50 - 500") |
Projection distance (tele) | 2.4 - 23.8 m |
Projector native resolution | WUXGA (1920x1200) |
Projection technology | 3LCD |
Matrix size | 1.7 cm (0.67") |
Service life of light source (economic mode) | 30000 h |
Service life of light source | 20000 h |
Light source type | Laser |
