Number of Processors Installed | 1 |
Performance-core base frequency | 1.7 GHz |
Efficient cores | 8 |
Performance cores | 6 |
Processor boost frequency | 4.8 GHz |
Efficient-core base frequency | 1.2 GHz |
Processor generation | Intel® Core™ i5 (14th gen) |
Efficient-core Max Turbo Frequency | 3.4 GHz |
Performance-core Max Turbo Frequency | 4.8 GHz |
Processor base power | 35 W |
Maximum turbo power | 92 W |
Processor model | i5-14500T |
Number of processors supported | 1 |
Processor threads | 20 |
Processor family | Intel® Core™ i5 |
Processor cache type | Smart Cache |
Processor cache | 24 MB |
Processor cores | 14 |
Processor manufacturer | Intel |
Discrete graphics card | No |
On-board graphics card family | Intel® UHD Graphics |
On-board graphics card model | Intel UHD Graphics 770 |
Discrete graphics card model | Not available |
On-board GPU manufacturer | Intel |
Maximum on-board graphics card resolution | 7680 x 4320 pixels |
On-board graphics card | Yes |
Memory slots | 2x SO-DIMM |
Memory layout (slots x size) | 1 x 16 GB |
Maximum internal memory | 64 GB |
INTERNAL MEMORY | 16 GB |
Memory channels | Single-channel |
Internal memory type | DDR5-SDRAM |
Water cooling system | No |
Intel® vPro™ Platform Eligibility | Yes |
Placement supported | Horizontal/Vertical |
Chassis type | MFF |
Product colour | Black |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Power supply | 90 W |
Power supply input voltage | 100 - 240 V |
Power supply input frequency | 50/60 Hz |
Operating shock | 40 G |
Operating vibration | 0.26 G |
Non-operating altitude | -15.2 - 10668 m |
Non-operating vibration | 1.37 G |
Non-operating shock | 105 G |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 10 - 35 °C |
Operating altitude | -15.2 - 3048 m |
Storage temperature (T-T) | -40 - 65 °C |
Operating relative humidity (H-H) | 20 - 80% |
Depth | 178 mm |
Height | 182 mm |
Width | 36 mm |
Wi-Fi | Yes |
Ethernet LAN | Yes |
WLAN controller model | Intel Wi-Fi 6E AX211 |
WLAN controller manufacturer | Intel |
Ethernet LAN data rates | 100 |
Antenna type | 2x2 |
Bluetooth | Yes |
Wi-Fi standards | 802.11a |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Product Type | Mini PC |
Built-in speaker(s) | Yes |
PASSWORD PROTECTION | Yes |
Number of speakers | 1 |
Market positioning | Business |
Trusted Platform Module (TPM) version | 2.0 |
Trusted Platform Module (TPM) | Yes |
audio chip | Realtek ALC3204 |
MOTHERBOARD CHIPSET | Intel Q670 |
Power cable length | 1.8 m |
CABLES INCLUDED | AC |
Display included | No |
Operating system installed | Windows 11 Pro |
Operating system architecture | 64-bit |
OPERATING SYSTEM LANGUAGE | English |
Trial software | Activate Your Microsoft 365 For A 30 Day Trial |
Total SSDs capacity | 512 GB |
SSD form factor | M.2 |
Number of SSDs installed | 1 |
SSD interface | PCI Express 4.0 |
SSD Capacity | 512 GB |
COMPATIBLE MEMORY CARDS | Not supported |
Number of storage drives installed | 1 |
NVMe | Yes |
Raid Support | No |
SSD performance class | 35 |
M.2 SSD size | 2230 (22 x 30 mm) |
STORAGE MEDIA | SSD |
Optical drive type | No |
Total Storage Capacity | 512 GB |
Number of USB ports with PowerShare support | 1 |
PowerShare | Yes |
DC-in jack | Yes |
DisplayPort version | 1.4a |
Number of front audio ports | 1 |
DisplayPorts quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Number of rear USB ports | 4 |
Number of front USB ports | 2 |
Combo headphone/mic port | Yes |
HDMI version | 1.4b |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Sustainability certificates | EPEAT Climate + |
Sustainability compliance | Yes |
Doesn't contain | PVC/BFR |
PAIA version | GaBi version 1, 2024 |
Carbon emissions, logistics (kg of CO2e) | 2.353 |
Carbon emissions, energy usage (kg of CO2e) | 28.3265 |
Total carbon emissions, w/o use phase (kg of CO2e) | 62.1735 |
Carbon emissions, manufacturing (kg of CO2e) | 59.368 |
Carbon emissions, end-of-life (kg of CO2e) | 0.543 |
Total carbon footprint (kg of CO2e) | 90.5 |
