processor | 235T |
processor manufacturer | Intel |
processor family | Intel Core Ultra 5 |
processor generation | Intel Core Ultra (Series 2) |
number of CPU cores | 14 |
processor threads | 14 |
Processor Boost Frequency | 5 GHz |
performance cores | 6 |
Efficient Cores | 8 |
Leistungskern maximale Turbofrequenz | 5 GHz |
Effizienter Kern maximale Turbofrequenz | 4,4 GHz |
Power Fundamental frequency of the core | 2,2 GHz |
Efficient base frequency of the core | 1,6 GHz |
processor cache | 24 MB |
processor cache type | Smart Cache |
Number of processors installed | 1 |
Base performance of the processor | 35 W |
Maximum turbo performance | 114 W |
Neuronale Prozessoreinheit (NPU) | Intel AI Boost |
Eigenschaft | Trusted Platform Module (TPM) |
Von der NPU unterstützte AI-Software-Frameworks | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
Gesamtleistung des Prozessors bis zu | 27 TOPs |
NPU-Leistung bis zu | 13 TOPs |
GPU-Leistung bis zu | 6 TOPs |
Storage | |
storage capacity | 8 GB |
RAM memory maximum | 64 GB |
Internal storage type | DDR5-SDRAM |
storage layout | 1 x 8 GB |
memory card slots | 2x SO-DIMM |
memory channels | Einfach-Kanal |
storage data transfer rate | 5600 MT/s |
storage medium | |
total storage capacity | 512 GB |
storage media | SSD |
Number of installed storage drives | 1 |
Total capacity of the SSDs | 512 GB |
Number of SSD installed | 1 |
SSD storage capacity | 512 GB |
SSD interface | PCI Express 4.0 |
SSD form factor | M.2 |
graphic | |
Separates Grafikkartenmodell | Nicht verfügbar |
Hersteller der eingebauten GPU | Intel |
On-Board-Grafikadapterfamilie | Intel Graphics |
Eingebautes Grafikkartenmodell | Intel Graphics |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
wiring technology | 10/100/1000Base-T(X) |
LAN-Controller | Intel WGI219LM |
Top WLAN-Standard | Wi-Fi 6E (802.11ax) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
Manufacturer of WLAN controllers | Intel |
WLAN controller model | Intel Wi-Fi 6E AX211 |
antenna type | 2x2 |
The Antenna Design | Intern |
connections and interfaces | |
Number of USB 2.0 ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 2.1 |
Number of DisplayPort connections | 1 |
DisplayPorts-Version | 1.4a |
Number of Ethernet LAN ports (RJ-45) | 1 |
Number of rear USB ports | 4 |
Number of front USB ports | 2 |
Number of front audio connectors | 1 |
Design | |
case type | Micro PC |
Unterstützte Positionierung | Horizontal/Vertikal |
Lock-Type Cable Barrier | Kensington |
Product color | Schwarz |
Services | |
market positioning | Business |
motherboard chipset | Intel Q870 |
audio chip | Realtek ALC3204 |
Audio-System | High Definition Audio |
product type | Mini-PC |
Trusted Platform Module (TPM) version | 2.0 |
Software | |
Betriebssystemarchitektur | 64-Bit |
Installed operating system | Windows 11 Pro |
Testsoftware | Activate Your Microsoft 365 For A 30 Day Trial |
energy | |
power supply | 90 W |
Power Supply - Input Voltage | 100 - 240 V |
Power supply - input frequency | 50 / 60 Hz |
operating conditions | |
operating temperatur | 10 - 35 °C |
Storage temperature range | -40 - 65 °C |
Operating relative humidity | 20 - 80% |
humidity during storage | 5 - 95% |
operating height | -15,2 - 3048 m |
storage height | -15,2 - 10668 m |
vibrations in operation | 0,26 G |
Vibration out of order | 1,37 G |
Stoßfestigkeit in Betrieb | 40 G |
Stoßfestigkeit außer Betrieb | 105 G |
sustainability | |
sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Gold |
weight and dimensions | |
broad | 36 mm |
depth | 178 mm |
height | 182 mm |
Weight | 1,16 kg |
