Lenovo ThinkCentre M90s Gen5 is a Small Form Factor (SFF) business workstation designed specifically with the demanding needs of corporate use in mind.
Key Features:
- Operating System: Windows 11 Pro 64-bit
- 6-core Processor: Intel Core i7-14700 (20C/28T/33MB)
- Processor specifications: 8xP-core 2.1/5.3GHz, 12xE-core 1.5/4.2GHz
- Chipset: Intel Q670
- Graphics: Integrated Intel UHD Graphics 770
- Intel vPro Enterprise
- Memory: 32GB DDR5 4400MHz UDIMM (1x32)
- Maximum Memory: 128GB (4x32GB)
- Storage: 1TB SSD M.2 2280 PCIe 4.0x4 Performance NVMe Opal 2.0
- One free M.2 2280 SSD slot
- Additionally, 1x3.5"HDD and 1x2.5"HDD SATA slots
- Additional drives require installation bracket
- No optical drive
- Internal 1W speaker
- LAN: 100/1000M Gigabit Ethernet (Intel I219-LM)
- WLAN: Wi-Fi 6E 802.11ax & Bluetooth 5.3
- Included: Lenovo USB keyboard and optical USB mouse
- Front Panel: 4xUSB-A, 1xUSB-C 3.2 Gen2, 1x3.5mm audio combo, 1x3.5mm Mic
- Back Panel: 2xDisplayPort 1.4a(HBR2,DSC), HDMI 2.1 TMDS, 4xUSB-A Gen1, 1xRS232, RJ-45, 1x3.5mm Line Out
- Low profile card slots: PCIe 3.0 x1, PCIe 4.0 x16 ja PCIe 4.0 x16 (x4 signal)
- Maximum installable LP card size: 155mm (length), 70mm (height)
- Integrated TPM 2.0 security chip, TCG/FIPS 140-2 certified
- Kensington security lock slot (3x7mm)
- Internal power supply: 310W 90%
- Military-grade durability: MIL-STD-810H
- Basic warranty: 3 years Premier NBD on-site
- Weight: 5.3kg
Lenovo CO2 Offset Gen2 emission compensation
- The carbon dioxide emissions generated during the manufacturing, transportation, and electricity consumption of this device throughout its lifecycle have been compensated through the global Climeco organization, supporting UN-approved environmental projects.
Environmental and energy certifications
- ErP Lot 3, GREENGUARD®, RoHS compliant, TCO Certified 9.0
| Manufacturer?s estimate: Manufacturing-related CO2 emissions, kg | 346.2 |
| Manufacturer?s estimate: Product life cycle CO2 emissions, kg | 491 |
| Connections | USB-C |
| Processor number of cores | 20 |
| Graphic adapter | Intel UHD Graphics 770 |
| Processor clock speed, GHz | 5.40 |
| MOTHERBOARD CHIPSET | Intel Q670 |
| Processor model | Intel Core i7-14700 (Max. 5.40GHz, 20C, 33MB) |
| Power supply, W | 310 |
| Internal memory type | DDR5 |
| Dimensions W x D x H, mm | 92.5 x 297.7 x 339.5 |
| Processor manufacturer | Intel |
| Memory clock speed, MHz | 4400 |
| Weight, g | 5300 |
| Intel Virtualization technology | VT-x / VT-d / VT-rp |
| Graphics adapter family | Intel UHD Graphics |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| USB-A (USB 3.2) ports quantity | 8 |
| Bluetooth Version | 5.3 |
| WLAN type | Wi-Fi 6E |
| HDMI ports quantity | 1 |
| WLAN antennas | 2x2 |
| DisplayPorts quantity | 2 |
| USB-C (USB 3.2) ports quantity | 1 |
| Trusted Platform Module (TPM) version | 2.0 |
| Number of performance-cores | 8 |
| Number of efficient-cores | 12 |
| RS-232 ports quantity | 1 |
| Operating system provided | Windows 11 Pro |
| Total Storage Capacity | 1 TB SSD |
| INTERNAL MEMORY | 32 GB |
| Maximum internal memory, GB | 128 GB |
| Solid State Disk drive type | M.2 PCIe NVMe |
| Processor family | Intel Core i7 |
| Wireless LAN (WLAN) | Yes |
| Optical Drive | No |
| Raid Controller | No |
| Bluetooth | Yes |
| Intel HyperThreading | Yes |
| Intel vPro | No |
| Dedicated video memory (GB) | Uses system memory |
| Cable lock slot | Yes |
