Processor generation | Intel® Core™ i5 (14th gen) |
Processor manufacturer | Intel |
Processor frequency | 1.7 GHz |
Processor model | i5-14500T |
Processor boost frequency | 4.8 GHz |
Processor family | Intel® Core™ i5 |
Processor cores | 14 |
On-board graphics card family | Intel® UHD Graphics |
Discrete graphics card | No |
On-board graphics card | Yes |
On-board graphics card model | Intel UHD Graphics 770 |
Discrete graphics card model | Not available |
Memory slots | 2x SO-DIMM |
Memory layout (slots x size) | 1 x 16 GB |
Memory clock speed | 4800 MHz |
Maximum internal memory | 64 GB |
Internal memory type | DDR5-SDRAM |
INTERNAL MEMORY | 16 GB |
Colour name | Black |
Chassis type | Mini PC |
Volume | 1 L |
Product colour | Black |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Power supply | 135 W |
Power supply input voltage | 100 - 240 V |
Power supply input frequency | 50 - 60 Hz |
Non-operating altitude | 0 - 12192 m |
Storage temperature (T-T) | -40 - 60 °C |
Operating altitude | 0 - 3048 m |
Operating temperature (T-T) | 5 - 35 °C |
Operating relative humidity (H-H) | 20 - 80% |
Storage relative humidity (H-H) | 10 - 90% |
Height | 36.5 mm |
Width | 179 mm |
Depth | 182.9 mm |
Weight | 1.25 kg |
WLAN controller manufacturer | Intel |
Wi-Fi standards | Wi-Fi 6E (802.11ax) |
Wi-Fi | Yes |
Ethernet LAN | Yes |
WLAN controller model | Intel Wi-Fi 6E AX211 |
Ethernet LAN data rates | 100 |
Bluetooth | Yes |
Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
Antenna type | 2x2 |
Product Type | Mini PC |
Number of speakers | 1 |
MOTHERBOARD CHIPSET | Intel Q670 |
audio chip | Realtek ALC233VB |
Audio system | High Definition Audio |
Trusted Platform Module (TPM) | Yes |
Mouse included | Yes |
Keyboard Included | Yes |
Display included | No |
Operating system installed | Windows 11 Pro |
Operating system architecture | 64-bit |
Card reader integrated | No |
SSD Capacity | 512 GB |
Number of SSDs installed | 1 |
SSD form factor | M.2 |
SSD interface | PCI Express 4.0 |
NVMe | Yes |
Total SSDs capacity | 512 GB |
Optical drive type | No |
Total Storage Capacity | 512 GB |
STORAGE MEDIA | SSD |
HDMI version | 2.1 |
HDMI ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
Combo headphone/mic port | Yes |
DisplayPorts quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
