processor | 6305E |
processor manufacturer | Intel |
processor family | Intel® Celeron® |
number of CPU cores | 2 |
processor threads | 2 |
processor clock speed | 1,8 GHz |
processor cache | 4 MB |
processor cache type | Smart Cache |
Number of processors installed | 1 |
Storage | |
storage capacity | 8 GB |
RAM memory maximum | 16 GB |
Internal storage type | DDR4-SDRAM |
storage layout | 1 x 8 GB |
memory clock speed | 3200 MHz |
memory channels | Zweikanalig |
storage medium | |
total storage capacity | 256 GB |
storage media | SSD |
Number of installed storage drives | 1 |
Total capacity of the SSDs | 256 GB |
Number of SSD installed | 1 |
SSD storage capacity | 256 GB |
SSD interface | PCI Express 4.0 |
Eigenschaft | Tastatur enthalten |
SSD form factor | M.2 |
M.2 SSD size | 2280 (22 x 80 mm) |
RAID Level | 0, 1 |
graphic | |
Separates Grafikkartenmodell | Nicht verfügbar |
Hersteller der eingebauten GPU | Intel |
On-Board-Grafikadapterfamilie | Intel® UHD Graphics |
Eingebautes Grafikkartenmodell | Intel® UHD Graphics |
network | |
Ethernet LAN data transfer rates | 1000,2500 Mbit/s |
Top WLAN-Standard | Wi-Fi 6 (802.11ax) |
WLAN-Standards | Wi-Fi 6 (802.11ax) |
Manufacturer of WLAN controllers | Intel |
WLAN controller model | Intel Wi-Fi 6 AX201 |
antenna type | 2x2 |
Bluetooth-Version | 5.1 |
connections and interfaces | |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 3 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports | 1 |
Number of Thunderbolt 4 ports | 1 |
Number of HDMI ports | 1 |
HDMI-Version | 1.4b |
Number of Ethernet LAN ports (RJ-45) | 2 |
Number of serial ports | 2 |
Design | |
case type | Mini PC |
name of the color | Black |
Unterstützte Positionierung | Horizontal |
Lock-Type Cable Barrier | Kensington |
Product color | Schwarz |
Services | |
motherboard chipset | Intel SoC |
product type | Mini-PC |
Trusted Platform Module (TPM) version | 2.0 |
Software | |
operating system language | Deutsch |
Installed operating system | Windows 11 IoT Enterprise |
energy | |
power supply | 65 W |
Power Supply - Input Voltage | 100 - 240 V |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 85 °C |
certificates | |
Konformitätsbescheinigungen | REACH, RoHS |
certification | ErP Lot 6/26PCFTED (ECO-declaration) |
weight and dimensions | |
broad | 179 mm |
depth | 88 mm |
height | 51,5 mm |
Weight | 1,02 kg |
package weight | 4,11 kg |
scope of delivery | |
mouse connectivity | Kabelgebunden |
Keyboard Connectivity | Kabelgebunden |
