Processor manufacturer | Intel |
Processor boost frequency | 4.2 GHz |
Processor cache | 8 MB |
Processor family | Intel® Core™ i5 |
Processor lithography | 10 nm |
Processor threads | 8 |
Built-in processor | Yes |
Processor model | i5-1135G7 |
Processor cores | 4 |
CPU configuration (max) | 1 |
Processor generation | 11th gen Intel® Core™ i5 |
Maximum Resolution | 4096 x 2304 pixels |
On-board graphics card model | Intel Iris Xe Graphics |
On-board graphics card | Yes |
Graphics card family | Intel |
Number of memory slots | 2 |
Maximum internal memory | 64 GB |
Supported memory clock speeds | 3200 |
Memory voltage | 1.2 V |
Memory slots type | SO-DIMM |
Supported memory types | DDR4-SDRAM |
Memory channels | Dual-channel |
Cable lock slot type | Kensington |
LED indicators | HDD |
Cable lock slot | Yes |
Product colour | Black |
VESA mounting | Yes |
Cooling type | Active |
Housing material | Metal |
Chassis type | 1.35L sized PC |
Product Type | Mini PC barebone |
AC input frequency | 50 - 60 Hz |
AC adapter output current | 4.74 A |
AC input voltage | 100 - 240 V |
AC adapter output voltage | 19 V |
Number of power supply units | 1 |
Power supply | 90 W |
Power supply type | External AC adapter |
Operating relative humidity (H-H) | 10 - 90% |
Operating temperature (T-T) | 0 - 50 °C |
Depth | 165 mm |
Weight | 1.3 kg |
Width | 190 mm |
Height | 43 mm |
PACKAGE WEIGHT | 2.1 kg |
LAN controller | Intel® I211 |
Wi-Fi | No |
Ethernet LAN | Yes |
Trusted Platform Module (TPM) version | 2.0 |
BIOS Type | UEFI AMI |
MOTHERBOARD CHIPSET | Intel SoC |
Number of processors supported | 1 |
Audio output channels | 5.1 channels |
AC adapter included | Yes |
Power cord included | Yes |
Drivers included | Yes |
PCI Express slots version | 4.0 |
Number of M.2 (M) slots | 1 |
Embedded options available | No |
Intel Stable Image Platform Program (SIPP) | No |
Intel Trusted Execution Technology | No |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Idle States | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Operating system installed | No |
Linux operating systems supported | Yes |
Windows operating systems supported | Windows 10 |
Built-in speaker(s) | No |
Storage drive sizes supported | M.2 |
Card reader integrated | Yes |
Number of storage drives supported | 2 |
Storage drive interface | PCI Express, Serial ATA III |
Supported storage drive types | HDD & SSD |
COMPATIBLE MEMORY CARDS | SD |
Serial ports quantity | 2 |
DC-in jack | Yes |
HDMI version | 2.0b |
Microphone in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 2 |
HDMI ports quantity | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Country of origin | China |
Harmonized System (HS) code | 84713000 |
