screen | |
screen size | 61 cm (24") |
Display resolution | 1920 x 1200 Pixel |
brightness (typical) | 400 cd/m² |
reaction time | 5 ms |
contrast ratio | 1000:1 |
angle of view, horizontal | 160° |
angle of view, vertical | 160° |
pixels spacing | 0,270 x 0,270 mm |
Horizontal scan area | 24 - 83 kHz |
Vertical scan area | 50 - 76 Hz |
connections and interfaces | |
More connections | USB 2.0 Hub: self-powered, four ports (cable included) |
Number of VGA (D-Sub) connections | 1 |
Number of DVI-D connectors | 1 |
Ergonomics | |
Panel mounting interface | 100 x 100 mm |
Eigenschaft | Plug & Play |
Lock-Type Cable Barrier | Kensington |
Einstellbare Höhe (max.) | 13 cm |
swivel angle range | -45 - 45° |
tilt angle range | -5 - 35° |
Anzeigebewegungswinkel | Tilt range: -5° to +35° vertical tilt, swivel range: -45° to +45°, height adjust: 130 mm, pivot rotation |
energy | |
Power consumption (standard operation) | 85 W |
Power consumption (standby) | 2 W |
operating conditions | |
operating temperatur | 5 - 40 °C |
Storage temperature range | 20 - 60 °C |
Operating relative humidity | 20 - 80% |
humidity during storage | 5 - 95% |
weight and dimensions | |
Gerätebreite (inkl. Standfuß) | 556 mm |
Gerätetiefe (inkl. Standfuß) | 253 mm |
Gerätehöhe (inkl. Standfuß) | 521 mm |
Width (without stand) | 565 mm |
Depth (without stand) | 83 mm |
Height (without stand) | 421 mm |
Gewicht (ohne Standfuß) | 9,8 kg |
package weight | 12,8 kg |
Other functions | |
Country of origin | China |
Display | LCD |
Packaging dimensions (WxDxH) | 672 x 464 x 352 mm |
Dimensions (W x D x H) (in inches) | 565,4 x 301 x 526,8 mm (22.3 x 11.8 x 20.7") |
energy demand | 100 - 240 V, 50 / 60 Hz |
security properties | Kensington Lock-ready |
Maximum resolution | 1920 x 1200 Pixel |
Video-Pixelrate | 200 MHz |
Videoeingang | VGA and DVI-D connectors, HDCP support |
Audio enthalten | No audio included at platform level |
weight (imperial) | 21.8 lb |
Hinweis zu Abmessungen (Imperial) | with stand |
Hinweis zu Abmessungen (metrisch) | with stand |
Produktabmessungen mit Standfuß,imperial (B x T x H) | 565,4 x 301 x 526,8 mm (22.3 x 11.8 x 20.7") |
Produktabmessungen ohne Standfuß, imperial (B x T x H) | 565,4 x 82,8 x 371,1 mm (22.3 x 3.26 x 14.6") |
