Services | |
Product color | Graphit |
product type | Gruppen-Videokonferenzsystem |
swivel range | -25 - 25° |
tilt angle range | -15 - 15° |
Eigenschaft | Schnellstartübersicht |
Video | |
HD-Typ | 4K Ultra HD |
Supported video modes | 576p, 720p, 900p, 1440p, 2160p |
Maximum Frame Rate | 30 fps |
Audio | |
output level | 92/99 dB |
Line out impedance | 4 Ohm |
Output Voltage Total Distortion Factor THD | 2% |
RMS performance | 8 W |
microphone reception range | 4,5 m |
sample rates | 0 - 48 kHz |
connections and interfaces | |
Number of HDMI ports | 3 |
Number of HDMI output interfaces | 2 |
Number of HDMI input interfaces | 1 |
USB plug | USB Typ-A, USB Typ-C |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 3 |
Number of Ethernet LAN ports (RJ-45) | 1 |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Supported network protocols | IPv4, IPv6 |
Supported security algorithms | 128-bit AES |
Camera | |
digital zoom | 4x |
Horizontal field of view | 113° |
Vertical field of view | 80,7° |
diagonal field of view | 120° |
remote control interface | Bluetooth |
microphone | |
Microphone sensitivity | -36 dB |
microphone frequency | 90 - 16000 Hz |
Alignment of the built-in microphone | Omnidirektional |
Sound pressure level (max) | 90 dB |
Mikrofonanzahl | 6 |
logistic data | |
Shipping carton weight | 6,29 kg |
Shipping carton length | 804 mm |
Shipping box width | 200 mm |
Shipping carton height | 212 mm |
Goods tariff number (HS) | 85176990 |
battery | |
battery capacity | 0,675 Wh |
computer system | |
Supports Windows operating systems | Windows 10, Windows 11 |
Supports Mac operating systems | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 10 - 95% |
Storage temperature range | -40 - 70 °C |
heat dissipation | 64 BTU/h |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
amperage | 4,754 A |
DC input voltage | 19 V |
Rechargeable battery technology | Lithium |
battery capacity | 220 mAh |
Number of rechargeable batteries/batteries supported | 2 |
power plug type | Typ C |
weight and dimensions | |
broad | 719 mm |
depth | 101 mm |
height | 91,4 mm |
Weight | 4,03 kg |
package weight | 5,8 kg |
scope of delivery | |
Supplied cables | AC, Gleichstrom, HDMI, USB Typ-A auf USB Typ-C |
power cord length | 2,5 m |
HDMI cable length | 2 m |
