Services | |
Number of people | 24 Person(en) |
Product color | Silber |
product type | Multipoint Control Unit (MCU) |
swivel range | 100 - 100° |
tilt angle range | 30 - 30° |
Video | |
HD-Typ | Full HD |
Maximum Frame Rate | 60 fps |
Supported video formats | H.263+, H.264, H.265, Sorenson H.263 |
Dual-Stream | : H.239 (H.323)/BFCP (SIP), FECC: H.224/H.281, Sony VISCA and PELCO D/P |
Video-Codec | H.265/HEVC, H.264 High Profile, H.264, H.263, H.263+ |
Audio | |
frequency range | 8 - 4800 Hz |
Eigenschaft | Kabelsperre-Slot |
Supported audio formats | G.711, G.722.1 |
connections and interfaces | |
Number of HDMI ports | 3 |
Number of USB 2.0 ports | 3 |
Number of Ethernet LAN ports (RJ-45) | 1 |
Phono-Eingänge (RCA) | 2 |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Camera | |
Optical zoom | 12x |
Optischer Zoom (normaler Modus) | 12x |
Weitwinkelbereich Blickwinkel (normaler Modus) | 30° |
Angle of view (FOV) | 100° |
features | |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 10 - 95% |
Storage temperature range | -30 - 70 °C |
energy | |
AC input voltage | 100 - 240 V |
amperage | 0,7 A |
DC input voltage | 48 V |
Power consumption (standard operation) | 16 W |
Power consumption (max.) | 21 W |
weight and dimensions | |
broad | 330 mm |
depth | 183 mm |
height | 40 mm |
