Compliance certificates | RoHS |
Certification | CE |
Number of fans | 1 fan(s) |
Fan connector | 4-pin |
Until material | Aluminium |
Base plate material | Copper |
Number of heat pipes | 4 |
Product colour | Black |
Number of fins | 51 |
Power consumption (typical) | 0.96 W |
Thermal Design Power (TDP) | 180 W |
Rated voltage | 12 V |
Rated Current | 0.08 A |
PACKAGE WEIGHT | 993 g |
Heat pipes diameter | 6 mm |
Height | 159.4 mm |
Package width | 190 mm |
Cable length | 0.22 m |
Depth | 72 mm |
Fan dimensions (W x D x H) | 120 x 120 x 23 mm |
Package height | 190 mm |
Package depth | 115 mm |
Weight | 620 g |
Width | 127 mm |
Noise level (low speed) | 11 dB |
Fan Diameter | 12 cm |
Supported processor sockets | LGA 1155 (Socket H2) |
Bearing type | Fluid Dynamic Bearing (FDB) |
Suitable location | Processor |
Pulse-width modulation (PWM) support | Yes |
Type | Cooler |
Noise level (high speed) | 23.6 dB |
Rotational speed (max) | 1500 RPM |
Mounting Kit | Yes |
Manual | Yes |
Thermal grease | Yes |
Heatsink dimensions (W x D x H) | 127 x 47.4 x 159.4 mm |
Master (outer) case width | 400 mm |
Master (outer) case height | 410 mm |
Master (outer) case length | 475 mm |
Master (outer) case gross weight | 17.2 kg |
Products per master (outer) case | 16 pc(s) |
Harmonized System (HS) code | 84733080 |
Warnings | Do not touch the fan during operation. |
