Fan connector | 4-pin |
Number of fans | 1 fan(s) |
Until material | Aluminium |
Product colour | Nickel |
Material | Copper |
Power supply | 1.56 W |
Voltage | 12 V |
Fan dimensions (W x D x H) | 120 x 15 x 120 mm |
Height | 146 mm |
Heatsink weight | 390 g |
Depth | 87 mm |
PACKAGE WEIGHT | 1.18 kg |
Package height | 185 mm |
Package depth | 146 mm |
Package width | 142 mm |
Width | 128 mm |
Weight | 520 g |
Suitable for | Processor |
Maximum air pressure | 1.53 mmH2O |
Rotational speed with LNA (max) | 1400 RPM |
Mean time between failures (MTBF) | 150000 h |
Noise level (high speed) | 23.9 dB |
Rotational speed (min) | 450 RPM |
Airflow | 94.2 m³/h |
Rotational speed (max) | 1850 RPM |
Noise level with LNA (max) | 16.8 dB |
Bearing type | Self-Stabilising Oil-pressure Bearing (SSO) |
Pulse-width modulation (PWM) support | Yes |
Fan Diameter | 12 cm |
Airflow with LNA (max) | 70.8 m³/h |
Supported processor sockets | Socket AM2 |
Compatible processor series | Intel® Pentium® |
Type | Cooler |
Low-noise adaptor (LNA) | Yes |
Heatsink dimensions (W x D x H) | 128 x 70 x 146 mm |
Products per master (outer) case | 8 pc(s) |
Master (outer) case gross weight | 10.2 kg |
Master (outer) case height | 400 mm |
Master (outer) case length | 330 mm |
Master (outer) case width | 308 mm |
