Until material | Aluminium |
Material | Copper |
Product colour | Nickel |
Fan connector | 4-pin |
Number of fans | 1 fan(s) |
Power supply | 2.52 W |
Voltage | 12 V |
Package depth | 53 mm |
PACKAGE WEIGHT | 770 g |
Package height | 212 mm |
Width | 92 mm |
Depth | 37 mm |
Height | 114 mm |
Package width | 148 mm |
Weight | 465 g |
Heatsink weight | 390 g |
Fan dimensions (W x D x H) | 92 x 14 x 92 mm |
Type | Cooler |
Pulse-width modulation (PWM) support | Yes |
Compatible processor series | AMD A |
Airflow | 57.5 m³/h |
Rotational speed (max) | 2500 RPM |
Supported processor sockets | Socket AM4 |
Rotational speed (min) | 600 RPM |
Airflow with LNA (max) | 40.08 m³/h |
Maximum air pressure | 2.11 mmH2O |
Mean time between failures (MTBF) | 150000 h |
Bearing type | Self-Stabilising Oil-pressure Bearing (SSO) |
Suitable for | Processor |
Noise level (high speed) | 23.6 dB |
Rotational speed with LNA (max) | 1800 RPM |
Fan Diameter | 9.2 cm |
Noise level with LNA (max) | 14.08 dB |
Low-noise adaptor (LNA) | Yes |
Heatsink dimensions (W x D x H) | 92 x 23 x 114 mm |
Products per master (outer) case | 24 pc(s) |
Master (outer) case height | 460 mm |
Master (outer) case gross weight | 19.7 kg |
Master (outer) case length | 250 mm |
Master (outer) case width | 440 mm |
