Compatible processor series | AMD Ryzen™ 7 |
Processor manufacturer | AMD |
Processor Socket | Socket AM4 |
DirectX version | 12.0 |
Maximum Resolution | 4096 x 2160 pixels |
HDCP | Yes |
On-board graphics card | Yes |
Parallel processing technology support | CrossFireX |
Graphics card family | AMD |
Number of displays supported | 3 |
Power source type | ATX |
PC health monitoring | Fan |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
Motherboard form factor | micro ATX |
audio chip | Realtek ALC892 / Realtek ALC897 |
MOTHERBOARD CHIPSET | AMD B450 |
Windows operating systems supported | Windows 11 x64 |
Supported memory clock speeds | 2400 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
Memory slots type | DIMM |
Number of memory slots | 4 |
Supported memory types | DDR4-SDRAM |
Depth | 244 mm |
Width | 244 mm |
Wake-on-LAN ready | Yes |
LAN controller | Realtek RTL8111H |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wi-Fi | No |
Number of SATA III connectors | 4 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
USB 2.0 connectors | 2 |
EPS power connector (8-pin) | Yes |
TPM connector | Yes |
Number of chassis fan connectors | 3 |
Front panel audio connector | Yes |
Front panel connector | Yes |
ATX Power connector (24-pin) | Yes |
CPU fan connector | Yes |
Number of COM connectors | 1 |
Chassis intrusion connector | Yes |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
Bundled software | ASRock A-Tuning
ASRock Polychrome SYNC
ASRock XFast LAN |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, PCI Express 3.0, SATA III |
Raid Support | Yes |
RAID levels | 10 |
DVI-D ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB connector type | USB Type-A |
USB 2.0 ports quantity | 2 |
Headphone outputs | 1 |
Microphone in | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
HDMI version | 1.4 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
PCI Express x16 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 1 |
PCI Express x16 (Gen 2.x) slots | 1 |
