Processor manufacturer | AMD |
Processor Socket | Socket AM4 |
Compatible processor series | AMD Ryzen 3000 Series |
Maximum number of SMP processors | 1 |
DirectX version | 12.0 |
HDCP | Yes |
Parallel processing technology support | Quad-GPU CrossFireX |
Maximum Resolution | 4096 x 2160 pixels |
Audio output channels | 7.1 channels |
audio chip | Realtek ALC897 |
MOTHERBOARD CHIPSET | AMD B550 |
PC health monitoring | Voltage |
Motherboard chipset family | AMD |
Motherboard form factor | ATX |
Windows operating systems supported | Windows 10 x64 |
Supported memory clock speeds | 2933 |
Maximum internal memory | 128 GB |
Unbuffered memory | Yes |
Memory channels | Dual-channel |
ECC сompatibility | Non-ECC |
Number of memory slots | 4 |
Memory slots type | DIMM |
Supported memory types | DDR4-SDRAM |
Height | 330 mm |
Width | 305 mm |
Depth | 244 mm |
Wake-on-LAN ready | Yes |
LAN controller | Killer E3100G |
Wi-Fi | No |
Ethernet interface type | 2.5 Gigabit Ethernet |
Ethernet LAN | Yes |
Thunderbolt headers | 1 |
Number of chassis fan connectors | 5 |
USB 2.0 connectors | 3 |
ATX Power connector (24-pin) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
TPM connector | Yes |
Number of SATA III connectors | 6 |
CPU fan connector | Yes |
Front panel audio connector | Yes |
12V power connector | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
RGB LED pin header | Yes |
BIOS Type | UEFI AMI |
CABLES INCLUDED | SATA |
Drivers included | Yes |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, SATA III |
RAID levels | 1 |
Raid Support | Yes |
S/PDIF out port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
USB 2.0 ports quantity | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
Digital audio optical out | 1 |
HDMI version | 2.1 |
PS/2 ports quantity | 1 |
PCI Express x16 slots | 3 |
PCI Express x1 (Gen 3.x) slots | 1 |
Number of M.2 (M) slots | 2 |
Weight | 465 g |
Harmonized System (HS) code | 84733020 |
