Compatible processor series | 3rd Generation AMD Ryzen™ 3 |
Processor manufacturer | AMD |
Processor Socket | Socket AM4 |
Maximum number of SMP processors | 1 |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Motherboard chipset family | AMD |
MOTHERBOARD CHIPSET | AMD B550 |
Supported memory clock speeds | 3866 |
Maximum internal memory | 128 GB |
Supported memory types | DDR4-SDRAM |
Memory channels | Dual-channel |
Memory slots type | DIMM |
Number of memory slots | 4 |
Width | 305 mm |
Depth | 244 mm |
Wi-Fi | No |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Wake-on-LAN ready | Yes |
LAN controller | Realtek RTL8111H |
ATX Power connector (24-pin) | Yes |
Peripheral (Molex) power connectors (4-pin) | 4 |
Front panel audio connector | Yes |
Audio connector | Yes |
CPU fan connector | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
EPS power connector (8-pin) | Yes |
Number of COM connectors | 1 |
USB 2.0 connectors | 2 |
BIOS Type | UEFI |
Drivers included | Yes |
Supported storage drive interfaces | M.2, Serial ATA III |
RAID levels | 0 |
Ethernet LAN (RJ-45) ports | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
PS/2 ports quantity | 1 |
Microphone in | Yes |
